Three Cylinder Dryer industrial Widely Use
- 100 Set / Sets per Month
- Qingdao
- T/T Credit Card
-
Gold mining jaw crusher equipment for sale, stone crusher machine
-
First-rate high efficiency SZZ series self-centering vibrating screen with ISO 9001 Certificate
-
China leader manufacturer ZHAOXIN high efficiency thickener
-
Ore benefication thickener machine, dewatering thickener price
-
china high quality center drive thickener, thickening equipment
-
Shandong Province high efficiency center drive thickener NZ-12, thickening machine
Product Details
| Place of Origin: | Henan, China | Brand Name: | TengFei | Model Number: | FD2200 x 12000 |
| Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Three Cylinder Dryer:1.Low moisture content of final product
2.Easy maintenance
3. Large Capacity
4. Flexible operation
Three Cylinder Dryer
1. Brief Introduction
- The Three Cylinder Dryer is widely used for drying the chalk slags, coal powder, slags, clay and other materials in the building materials, metallurgy, chemical industry, cement industry.
- The Calcium Carbonate Dryer has a better adaptability and can dry various materials with a simple and reliable operation.
2. Technical Parameters
Specification (model) | Cylinder volume (m³) | Cylinder speed (r/min) | Cylinder gradient (°C) | Motor Model | Motor Power (KW) | Decelerator Model | Overall dimensions (MM) | Weight (T) |
FD600x8000 | 2.26 | 8 | YCT200-4A | 4 | JZQ250 | 8000x2200x980 | 2.9 | |
FD800x1200 | 5.02 | 7 | 3-5 | Y132M2-6 | 4 | JZQ250 | 12000x2700x1300 | 3.5 |
FD1000×10000 | 7.85 | 6.73 | 3-5 | Y132M2-6 | 4 | JZQ400 | 10000×1876×2069 | 7.5 |
FD1200×6000 | 6.8 | 5.8 | Y132M2-6 | 5.5 | JZQ500 | 6000×2159×2475 | 7.97 | |
FD1200×8000 | 9.1 | Y132M2-6 | 5.5 | JZQ500 | 8000×2159×2475 | 8.75 | ||
FD1200×10000 | 11.31 | Y160M-6 | 7.5 | JZQ500 | 10000×2159×2475 | 9.25 | ||
FD1200×12000 | 13.75 | Y160M-6 | 7.5 | JZQ500 | 12000×2159S×2475 | 10.3 | ||
FD1500×8000 | 14.14 | 4.8 | Y160L-6 | 11 | JZQ650 | 8000×2655×2859 | 14.74 | |
FD1500×10000 | Y160L-6 | 11 | JZQ650 | 10000×2655×2895 | 15.9 | |||
FD1500×12000 | 21.2 | Y180L-6 | 15 | JZQ650 | 12000×2055×2895 | 17.13 | ||
FD1500×14000 | 24.9 | Y180L-6 | 15 | JZQ650 | 14000×2655×2895 | 18.33 | ||
FD1800×10000 | 25.45 | 3-5 | 5 | Y180L-6 | 15 | JZQ650 | 10000×3060×2980 | 17.93 |
FD1800×12000 | 30.5 | Y200L-6 | 18.5 | JZQ650 | 12000×3060×2980 | 19.89 | ||
FD1800×14000 | 35.1 | Y200L-6 | 18.5 | JZQ650 | 14000×3060×2980 | 20.85 | ||
FD1800×18000 | 45.8 | Y200L-6 | 22 | JZQ650 | 18000×3060×2980 | 22.3 | ||
FD2200×12000 | 45.6 | 4.4 | Y200L-6 | 22 | JZQ750 | 12000×3620×3570 | 30.31 | |
FD2200×14000 | 53.2 | Y200L-6
| 22 | JZQ750 | 14000×3620×3570 | 32.23 | ||
FD2200×18000 | 68.4 | Y225M-6 | 30 | JZQ750 | 18000×3620×3570 | 34.15 | ||
FD2200×20000 | 70 | Y225M-6 | 30 | JZQ750 | 20000×3620×3570 | 36.07 | ||
FD2400×14000 | 63.3 | 3.85 | Y225M-6 | 30 | JZQ850 | 14000×3860×3760 | 39.9 |
3. Features of Three Cylinder Dryer
- Gas low temperature, dust removal equipment with long time
- The new type of composite feed device, easily control to the end of the moisture indicator
- High degree of automation,transmission powder is small,easy operation,stable running
- Fuel can adapt to coal,oil and gas.
4. Structure
- Heating system part uses the hot blast stove technology, sufficient heat and heat transfer effect is good,structure simple
- Heat exchange system is the drying cylinder, cylinder body feed plate staggered into spiral, repeatedly kick up materials, high heat efficiency
- Ventilation dust removal system is dust collecting equipment, after drying,the flyash under the nagative pressure condition, easy being taken away by the airflow, prevent the flyash be absort and discharged into the atmosphere by the induced draught system caused resource waste and environmental pollution,unified by the filter dust collector.
5. Working Site
1. Pre- sale service: our company can provide technological guidance and formulate suitable equipment matching program according with your specific production requirements.
2. On- purchase service: our company can solve professional technical problems and other related issues for you.
3. After- sales service: our company provides that engineers available to service machinery overseas and equipment for life maintenance.
