Vibration Screen for Marble

Specifications

Vibration Screen for Marble
1. Using eccentric block, strong exciting force
2. Flexible connection
3. Large capacity
4.safe



Vibration Screen for Marble

TengFei Quality





• Type: Necessary Equipment
• Input Size: 0-100mm
• Processed Materials: River Gravel, Marble, Granite, Basalt, Quartz, Iron ore, Diabase, Limestone, Coal Gangueetc.
• Applications: Aggregate Field, Concrete Mixing Plant, Dry Motar Plant Desulfurization, Quartz Sand etc.

Detailed Spcification of Vibration Screen for Marble

• Vibration Screen for Marble moves in a circular motion with multiple layers and high efficiency. The vibrating screen is designed with the barrel type of eccentric shaft vibration exciter and eccentric block to adjust the swing.
•  It is manufactured with long material screen rifling and many screen specifications. The vibrating screen is especially designed for screening stones and features reliable structure, strong vibration force, high screening efficiency, low vibrating noise, excellent durability, convenient maintenance, safe use, etc.

Model	Screen Size (mm)	No. of Layer	Screen mesh (mm)	Max. feed size (mm)	Handling capacity (t/h)	Motor power (Kw)	Vibrating frequency (r/min)
2YZS1237	3700×1200	2	3-100	400	10-80	11	750-950
3YZS1237	3700×1200	3	3-100	400	10-80	11	750-950
2YZS1548	4800×1500	2	3-100	400	30-200	15	750-950
3YZS1548	4800×1500	3	3-100	400	30-200	15	750-950
2YZS1848	4800×1800	2	3-100	400	50-250	18.5	750-950
3YZS1848	4800×1800	3	3-100	400	50-250	18.5	750-950
4YZS1848	4800×1800	4	3-100	400	50-250	18.5	750-950
