Home > Products > Circular Vibrating Screen > Flexible Connection Cobblestone Screen
Flexible Connection Cobblestone Screen
- 28 Set / Sets per Month
- Shanghai Ningnbo Tianjin etc.
- T/T Credit Card
Product Details
Condition: | New | Type: | Circular | Application: | Ore |
Place of Origin: | Henan, China | Brand Name: | TengFei | Model Number: | YZS Series |
Voltage: | 380v or required | Power(W): | 11-22kw | Dimension(L*W*H): | Different |
Weight: | 3.2t-12.78t | Certification: | ISO CE | Warranty: | 12 Months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Cobblestone Screen1. Using eccentric block, strong exciting force
2. Flexible connection
3. Larger capacity
Cobblestone Screen
TengFei Quality
Type | Necessary Equipment |
Input Size | 0-100mm |
Proccessed Materials | Kaolin, River Gravel, Granite, Basalt, Quartz, Iron ore, Diabase, Cobblestone, Coal Gangueetc. |
Application | Aggregate Field, Concrete Mixing Plant, Dry Motar Plant Desulfurization, Quartz Sand etc. |
Detailed Spcification of Cobblestone Screen
- Cobblestone Screen moves in a circular motion with multiple layers and high efficiency. The vibrating screen is designed with the barrel type of eccentric shaft vibration exciter and eccentric block to adjust the swing.
- It is manufactured with long material screen rifling and many screen specifications. The vibrating screen is especially designed for screening stones and features reliable structure, strong vibration force, high screening efficiency, low vibrating noise, excellent durability, convenient maintenance, safe use, etc.
Technical Parameters of Cobblestone Screen
Model | Screen Size (mm) | No. of Layer | Screen mesh (mm) | Max. feed size (mm) | Handling capacity (t/h) | Motor power (Kw) | Vibrating frequency (r/min) |
2YZS1237 | 3700×1200 | 2 | 3-100 | 400 | 10-80 | 11 | 750-950 |
3YZS1237 | 3700×1200 | 3 | 3-100 | 400 | 10-80 | 11 | 750-950 |
2YZS1548 | 4800×1500 | 2 | 3-100 | 400 | 30-200 | 15 | 750-950 |
3YZS1548 | 4800×1500 | 3 | 3-100 | 400 | 30-200 | 15 | 750-950 |
2YZS1848 | 4800×1800 | 2 | 3-100 | 400 | 50-250 | 18.5 | 750-950 |
3YZS1848 | 4800×1800 | 3 | 3-100 | 400 | 50-250 | 18.5 | 750-950 |
4YZS1848 | 4800×1800 | 4 | 3-100 | 400 | 50-250 | 18.5 | 750-950 |
Working Site
