PA-F Series ac dc voltage converter 220v 100v from China manufacture
- 20000 Piece / Pieces per Month
- Shanghai
- T/T Credit Card PayPal
-
ME Series Modules High Stability High Voltage Power Supply for Microchannel Plates
-
MMC Series DC High Stability Voltage Power Supply for Microchannel Plates (100V-600V,0.1W)
-
Brand new power box 640C0022G01 York control system motherboard power supply GLC75D-CVG
-
Power Supplies TVD1.3-15-03 Original Stock
-
10W 2.5KV Isolation Wide Input AC/DC Converters
-
30W Wide Voltage Input DC/DC Converters power supply
Product Details
| Place of Origin: | Jiangsu, China | Brand Name: | PengTu | Model Number: | PA-F Series 20-40W |
| Output Power: | 1 - 50W | Output Type: | Other, Single, Dual and Triple | Input Voltage: | 220V |
| Output Voltage: | 3.3~48V | Output Frequency: | 50~100KHz | Output Current: | 0-9.09A |
Product Description
PA-F Series 20-40W voltage converter 220v 100v
Notice:
We do have enough ability to produce custom-made order.
Samples are available
High quality and low price .
If need samples, Kindly contact us
2 years warranty
If you can not find the required products below, pls feel free contact with us! We can supply you all kinds of power converter and switching power supply.
Features
l Wide input voltage
l Broadband noise filter of input
l Comply with UL1950, IEC950 safety regulation
l Nice shape design
l Pin function compatible
l Fast dynamic response
Input Characteristic
l Inputvoltage range……………………85 ~ 264 VAC Rated value: 220VAC
Reverse Protection
Fuse Outside
Output Characteristic
l Voltage accuracy …….................…………±2%
l Line regulation(main) ………………........±0.2%
l Load regulation(main) …………….......…±0.4%
l Temperature coefficient …………........…±0.01%/℃
l Output current limiting ………….........… 120%(Typ)
l Dynamic response ……………………… 400μs
l Output current …………………………… 0-9.09A
l Output voltage …………………………… 3.3-48VDC
l Power …………………………………… 20-40W
General Characteristic
l Switching frequency …………………… 50-100 KHz
l Isolation resistance …………………… 200 MΩ
l MTBF ………………………………… >500000H
l Isolation voltage
Input-output:>2000 VAC/Min (Leakage current<5mA)
Input-case: >2000 VAC /Min (Leakage current<5mA)
Output-case: >500 VDC/Min
l Environmental Characteristic
Case temperature …………………… Industry: -25-+85℃
Storage temperature ……………….. Industry: -45~ +105℃
Models
| Model | Output Lines | Input V. (V) | Input V. Range (V) | Output V.(V) | Output Curr.(A) | Ripple (mv) | Efficieency (Typ) |
| PA-F Series 20-40W | |||||||
| PA20-220S3.3-F | Single | 220 | 85-264 | 3.3 | 6.06 | 50 | 77% |
| PA20-220S05-F | 220 | 85-264 | 5 | 4 | 50 | 77% | |
| PA20-220S12-F | 220 | 85-264 | 12 | 1.667 | 100 | 79% | |
| PA20-220S24-F | 220 | 85-264 | 24 | 0.833 | 150 | 80% | |
| PA30-220S05-F | 220 | 85-264 | 05 | 6 | 50 | 77% | |
| PA40-220S12-F | 220 | 85-264 | 12 | 3.33 | 100 | 79% | |
| PA40-220S24-F | 220 | 85-264 | 24 | 1.66 | 150 | 80% | |
| PA30-220D05&05-F | Dual | 220 | 85-264 | 05&05 | 3&3 | 80/120 | 80% |
| PA30-220D12&12-F | 220 | 85-264 | 12&12 | 1.25&1.25 | 80/120 | 80% | |
| PA30-220D12&24-F | 220 | 85-264 | 12&24 | 1.25&0.63 | 80/120 | 81% | |
| PA40-220D05&05-F | 220 | 85-264 | 05&05 | 4&4 | 80/120 | 77% | |
| PA40-220D05&12-F | 220 | 85-264 | 05&12 | 2&3 | 80/120 | 84% | |
| PA40-220D05&24-F | 220 | 85-264 | 05&24 | 2&1.25 | 80/120 | 78% | |
| PA40-220T05&12&12-F | 220 | 85-264 | 05&12&12 | 3&-1.04&1.04 | 80/120/120 | 78% | |
| PA40-220T05&12&24-F | 220 | 85-264 | 05&12&24 | 3&1&0.5 | 80/120/240 | 78% | |
Remarks: Custom-made specifications are acceptable.
Mechanical drawing and pin definition
Our service
1.Your inquiry will be reply within 24hours
2.Well-trained and experienced staffs to answer all your inquiries in English
3.We have strictly management on the production and quality control
4.We have our own factory and professional engineers team to help you to resolve the prombles
5.We are greatly to accept the sample order for testing our quality ,serive and your market
Warranty term
1. Under the terms of this warranty, if the product have a failure occurs under normal usage within warranty period, we will provide free new products or components based on the proof-documents.
2. If Failure or damage due to incorrect operation, wire connection, or anything other do not follow our instuction, we will provide paid .36w
If you want to know more information ,pls feel free to contact us. Any feedback from you will be gave the prompt attention and reply!
