Home > Products > Enameled Copper Wire > China Manufacturing Copper Wire For Winding Motors
China Manufacturing Copper Wire For Winding Motors
- 1500 Ton / Tons per Month
- Qingdao TianJin ShangHai
- T/T L/C D/P D/A Credit Card PayPal
-
Power Accessories Photovoltaic lines Wires UL10269 high voltage cable
-
Factory Direct House Wiring 2.5mm2 Single Core Flexible Copper Wire Electrical Wire Installation Electric Cables Price
-
XTW CXWT 300V UL62 PVC FIexible Cord
-
Enameled Copper wire
-
3x185mm2 Overhead Insulated Cable
-
Service Drop Cable XLPE/PVC/PE Insulated
Product Details
| Place of Origin: | Henan, China | Brand Name: | MG | Model Number: | Enameled copper wire |
| Type: | Insulated | Application: | Other, For transformer/electrical motor, Instrumentation winding, transformers, telecommunications equipment | Conductor Material: | Copper |
| Conductor Type: | Solid | Insulation Material: | Enameled |
Product Description
Specifications
Copper Wire For Winding Motors1. Size: 0.025mm-4.5mm
2. Thermal Class: 130-220C
3. Standard: IEC, NEMA,GB
Copper Wire For Winding Motors
Our Company’s annual production is about 8,000 tons.
Our Company covers almost 100,000 square meters, including plant area of 80,000 square meters.
We have many kinds of products ,such as enameled aluminum wire, enameled copper wire, paper covered magnet wire, fiber glass covered magnet wire and so on.
We produce the thermal class of enameled aluminum wire from 130 to 220 Centigrade.
Gauge of enameled aluminum wire:Enameled round aluminum wire: 0.2mm-8.0mm Enameled flat aluminum wire: a: 1-10mm, b: 3-16mm.
HENAN MG MAGNET WIRE.,LTD. is a professional supplier of magnet wires and electrical materials. From the company founded till now, our company has been committed to providing professional Enameled Magnet wires , winding Magnet Wires and Electrical materials for customers.
An experienced,well mannered sales and marketing team are committed to bring the buyers Satisfactory products and services . In order to succeed in the enameled wire and winding wire market, our company has instituted a development policy that emphasizes "Serving the customer, improving products, sureness and steadiness,providing best service,devotion and dedication".Please feel free to contact us.
We will try our best to send the Copper Wire For Winding Motors to your city as soon as possible. Carton and wooden box will be used as double protection to protect the product from wear and tear during transport.
1. Features of Copper Wire For Winding Motors
a) High cut through
b) Good electrical conductivity
c) Good wear resistance and corrosion resistance
d) Excellent heat shock,adherence and flexibility
2. Advantage of our product
♦ Square Wire are available
♦ Varieties of wires,Stable quality
♦ Timely, continuous after-sales service
♦ Professional Tech and sales Work Team
♦ Safe and variety packing terms are available
♦ Double or Three Type Insulation covered wires are available
♦ NEMA/IEC/JIS/GB and any Local Standards base on requirements
3.Reference parameter as follows
Name | Enameled Copper Wire | ||
Type | Q(ZY/XY)-1/200 | ||
Diameter | 1.0mm | ||
Standard | IEC60317 | ||
Test Item | Unit | Technical Requirement | Test Result |
Appearance |
| bright and clean, Uniform color, | Ok |
Overall Diameter | mm | <=1.062mm | 1.06 |
Conductor Diameter | mm | 1.000±0.010mm | 1 |
Roundness Tolerance | mm | <=0.010 mm | 0.002 |
Thickness of insulation film | mm | >= 0.034 mm | 0.06 |
Elongation |
| >=30 % | 40% |
spring-back angle |
| <=42 | 36 |
Flexibility and adhesion | winding test | 1D | 1 |
Jerk test | No Crack, and No losing adhesion | OK | |
heat shock |
| 2.24mm | ok |
cut-through resistance |
| 320C, 2Min no breakdown | 2 |
Resistance to solvent |
| 1H | 1 |
Breakdown Voltage | KV | >=2.7 KV | 6.7 7.2 6.2 7.8 7.0 |
scratch resisting(Average) | N | 7.05 N | 21.5 |
scratch resisting(Min) | N | 5.95 N | 19.3 |
package |
| Meet the export standards | Ok |
Enamel Film continuity |
| <=25 /30m | 0 |
Quality Control Result |
| Ok | |
Contact Us
- Henan Mg Magnet Wire Co., Ltd.
- Contact nameMiss Dong
- Phone0086-371-55625861
- Address No. 38,NongKe Road, Jinshui Zone, Zhengzhou City, Henan Pro. China. Zhengzhou,Henan
-
