Industrial Rugged IP65 Tablet JK-i8000

Industrial Rugged IP65 Tablet JK-i8000 thumbnail-1
Industrial Rugged IP65 Tablet JK-i8000 thumbnail-2
Industrial Rugged IP65 Tablet JK-i8000 thumbnail-3
Industrial Rugged IP65 Tablet JK-i8000 photo-1
Industrial Rugged IP65 Tablet JK-i8000 photo-2
Industrial Rugged IP65 Tablet JK-i8000 photo-3
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Screen Size:
Other, 7"
Display resolution:
1024x600
Contact Supplier Request Quote Chat Now
Shenzhen Instantware Information Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/HK
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Screen Size Other, 7"
Display resolution 1024x600
Weight 450g
Place of Origin Guangdong, China
Brand Name INST
Model Number JK-i8000
Color Black
Operating System Android 2.3

Rugged Table JK-i8000



High Industrial Grade / Wireless Data Collection

Ergonomic Keypad / Capacitive Multi-touch Screen



Industrial Rugged IP65 Tablet JK-i8000

JK-i8000 adopts ergonomic design for easy operation and supports outdoor visualization of screen display by fully taking into account the application environment of the customer while providing the properties of a special industry device. With IP 65 rating, high-capacity battery and extra-low power consumption, it is allowed to serve under harsh environment for a long time. It is designed for use in warehouse management, logistics, transportation management, e-commerce, law enforcement and other industrial areas.

Industrial Rugged IP65 Tablet JK-i8000



Multiple Data Collection

Strong, various data collection methods include 1D/2D bar code scanning and RFID read/write

Adaptability and Mobility

Ergonomic design with high durability and mobility; supports outdoor visualization with high-brightness or transflective screen.

High Industrial Application Level

Industrial protection grade of IP65, 1.5m drop to concrete and support various industrial applications even in extreme working environments.

Wireless Communication

Support wireless communication modes of WiFi, GPRS/GSM, 3G and Bluetooth

Large Battery Capacity

Extra-large battery capacity and extra-low power consumption to provide service time of more than 8 hours.

Flexible Application Development

Support dual-system of Windows CE 6.0 & android 2.3; SDK provided to satisfy flexible customization in different applications



Application Fields:

Transportation & Logistics / Garment & Chain Store / Retail Market / Wholesale Trade /  Healthcare & Hospitality / E-commerce / Law Enforcement / Manufacturing

Industrial Rugged IP65 Tablet JK-i8000

JK-i8000 Specification
Physical
Characteristics		 Dimentions 240*130*20mm
Weight 450g(include battery)
Display Transflective TFT daylight readable color display; support multi-touch (> 4 points) 1024 x 600 pixels; 7 inch capacitive touch screen
Keyboard Support entity key-board input (numeric/Alphabetic keys x 12, diretional keys x 4, function keys x 10, scan button x 1)
Input Chinese, English, handwriting, support soft keyboard
Power Main Battery Removable, rechargeable 3.7V 5000mAh lithium battery pack,which can work for eight hours or above (depending on environment).
RTC Battery Individual RTC to keep clock at real time
Performance
Characteristics		 O.S. Microsoft Windows CE 6.0 R3 & Android 2.3 (multi-language)
CPU 1GHz
Memory ROM 256MB-1G
RAM 512MB-1G
Expansion Micro SD/TF x 1, SIM x 1, PSAM x 1
Audio loudspeaker x 1, Microphone x 1
Interfaces USB host x 1, mini USB x 1, 3.5mm Andio Jack x 1
Barcode Scanner 1D Laser Scanning Rate 100±20scan/sec
Decode
Capability		 UPC-A,UPC-E,UPC-E1,EAN-8,EAN-13,Bookland EAN,
Code39,Codabar,Code128,Disrete 2 of 5;IATA 2 of 5;Interleaved 2 of 5;Code 93;UPC A;UPC E0;EAN 8;EAN 13;MSI;EAN 128;UPC E1:
Trioptic Code 39;Bookland EAN;Coupon Code; RSS-Limited;RSS-14;RSS-Expanded;
2D CMOS Scanning Rate 100±20scan/sec
Decode
Capability		 1D Symbologies: UPC/EAN,Bookland EAN,UCC Coupon Code,ESSN EAN,CODE 39,CODE 128,GS1-128,ISBT 128,Trioptic Code 39,CODABAR,MSI,Interleaved 2/5,Discrete 2/5,Chinese 2/5,Korean3/5,Matrix 2/5, CODE 32,CODE 93,CODE 11,Inverse 1D,GS1 DataBar,Composite Codes
2D Symbologies: PDF417,MicroPDF417,Data Matrix,Data Matrix inverse,MaxiCode,QR Code,Aztec,Aztec Inverse
Postal Codes: U.S.Postnet,U.S.Planet,U.K.Postal,Japan Postal,Australian Postal,Netherlands KIX Code,USPS 4CB/One Code/Intelligent Mail,UPU FICS Postal
Wireless
Communication 		Wi-Fi WLAN WIFI 802.11b/g Frequency range: 54MB/sec; Cisco Compatible CCX2/3 Security,CISCO AP Security
WAN Frequency Range GSM 850/900/1800/1900MHz
Data Rate GPRS multi-slot Class 10:DL 85.6 kbps/UL 42.8kbps
GPRS multi-slot Class 8: DL 85.6 kbps/UL 21.4kbps
WCDMA Frequency Range UMTS2100/900 MHz
UMTS1900/850 MHz
GSM850/900/1800/1900 MHz
Data Rate GSM CS: UL 9.6kbps/DL 9.6kbps
GPRS/EDGE: Multi-slot Class 12, Class B
WCDMA CS: UL 64kbps/DL 64kbps
WCDMA PS: UL 384kbps/DL 384kbps
HSDPA: DL 3.6Mbps
CDMA 2000 Frequency Range CDMA2000 1x,CDMA2000 EV-DO Rev. 0,
CDMA2000 EV-DO Rev. A
Supports BC0(800MHz band), BC1(1900MHz band)
Data Rate CDMA2000 1X: UL/DL: 153.6kbps
CDMA2000 1X/EV-DO REV.0: UL 153.6kbps DL 2.4Mbps
CDMA2000 1X/EV-DO REV.A: UL 1.8Mbps DL 3.1Mbps
Options Bluetooth Bluetooth Class 2.1 + EDR
Camera Front:facing camera:1.3 mega piexls;rear camera:5.0 mega piexls:automatic focus
GPS Support A-GPS
RFID Customizable, support:
LF: ISO11784/11785;
HF: ISO15693, ISO14443A/B, SRI513/SRI4K
UHF: ISO180006B (EPC C1 Gen1), ISO18000-6C
User
Environment		 Operating Temperature -10°C to +50°C
Storage Temperature -20°C to +60°C
Humidity 5% to 95% non condensing (Condensation Resistant Configurations Available)
Drop Multiple drops to concrete: 5ft./1.5m across the operating temperature range
Sealing IP56 rated, water and dust resistent
Peripherals
and Accessories		 Printers Supports extensive line of Bluetooth SPP approved printer and cables
Other Acceseries Adaptor, USB Cradle Cable
Regulatory Product Certification CCC, CE
Electrical Safety Certified to UL60950, CSA C22.2 No.6050, EN60950/IEC950
Laser Safety IEC Class 2/FDA Class II, in accordance with IEC60825-/EN60825-1
Warranty 12 months (except the accessories)
