Specifications of Water-Cooled Copper Condenser
we produce all the condenser and evaporator according to customer requiment
Our commercial freezer condenser carry out ISO standard and get RoHS report,we already supply to some famous manufacturer in Europe and China.
copper tube diameter: 5/16 and 3/8
type of copper tube:inner screw thread/inner grooved pipe or bare/smooth pipe.
aluminum foil: hydrophilic or bare.
fin type: flat or corrugated or sine-wave
Slide plate: galvanized steel plate.
aluminum fin space:can up to 7.5mm max
pitch of holes and pitch of rows: 25*21.65mm and 31.75*27.5mm.
product length: up to 4meters.
product height: not limited
Size from 1/4HP to 20HP
available temperature is above -40 degree.
We can supply according to your drawings or samples,also we can design as you need.
commercial freezer condenser,fin type condenser,heat exchanger,copper condenser, aluminum condenser,condenser coil,refrigerator condenser,fridge condenser,freezer condenser,air-conditioner condenser,refrigeration parts,HVAC parts.
FIN MOLD:
| NO. | COPPER TUBE DIAMETER | HOLES PITCH AND ROWS PITCH | FIN SPACE | HOLES ARRAY | FIN SURFACE | FIN EDGE TYPE | DEFROST HEATER |
| 1 | φ15.88mm | 38.1*33mm | 3-9mm | EQUILATERAL TRIANGLE | FLAT | FLAT+WAVE | WITHOUT |
| 2 | φ12.7mm | 31.75*27.5mm | 3-9mm | EQUILATERAL TRIANGLE | SIN-WAVE&CORRUGATED | FLAT+WAVE | WITH |
| 3 | φ12mm | 35*35mm | 3-9mm | SQUARE | SIN-WAVE&CORRUGATED | FLAT+WAVE | WITH |
| 4 | φ9.52mm | 25*21.65mm | 1.5-6mm | EQUILATERAL TRIANGLE | SIN-WAVE&CORRUGATED | FLAT+WAVE | WITH |
| 5 | φ9.52mm | 31.75*27.5mm | 2.5-7.5mm | EQUILATERAL TRIANGLE | SIN-WAVE&CORRUGATED | FLAT+WAVE | WITH |
| 6 | φ9.52mm | 25*21.65mm | 1.5-5.5mm | EQUILATERAL TRIANGLE | FLAT&CORRUGATED&LOUVER BRIDGE WINDOWS | FLAT | WITHOUT |
| 7 | φ9.52mm | 25.4*19.05mm | 1.5-3.5mm | EQUILATERAL TRIANGLE | SIN-WAVE&CORRUGATED | FLAT+WAVE | WITHOUT |
| 8 | φ9.52mm | 25.4*15.88mm | 1.5-3.5mm | EQUILATERAL TRIANGLE | SIN-WAVE&CORRUGATED | FLAT+WAVE | WITHOUT |
| 9 | φ7.94mm | 25*21.65mm | 1.5-3.5mm | EQUILATERAL TRIANGLE | FLAT | FLAT+WAVE | WITHOUT |
| 10 | φ7.94mm | 25.4*15.88mm | 1.5-3.0mm | EQUILATERAL TRIANGLE | SIN-WAVE&CORRUGATED | FLAT+WAVE | WITHOUT |
| 11 | φ7mm | 21*12.7mm | 1.3-2.3mm | EQUILATERAL TRIANGLE | FLAT&CORRUGATED&LOUVER BRIDGE WINDOWS | FLAT | WITHOUT |
