Perforated Textured HDPE Geocell

Name: Perforated Textured HDPE Geocell
Brand: OEM or ROAD
SKU: 115441027
Availability: InStock

US$ 1 - 6 MOQ: 2000 Square Meters

Key Specifications

Place of Origin:

Brand Name:

OEM or ROAD

Model Number:

TGLG-50-400 TGLG-100-400 TGLG-150-400 TGLG-200-400

Taian Road Engineering Materials Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Brand Name OEM or ROAD

Model Number TGLG-50-400 TGLG-100-400 TGLG-150-400 TGLG-200-400

Material PP

Specifications

1)HDPE Textured geocell
2)perforated
3)height:50~200mm
4)welding distance:300`800mm

Introduction: Geocell is a net-shaped cell structure made by welding high intensity thermoplastic

sheet. It is flexible and folded during transportation, stretching out and being filled with stone or

concrete during service, and forming into structure with powerful lateral confinement and rigidity

Functions:

1.Geocell can be used as cushion coat to strengthen loading capacity of weak ground

2.Geocell can paved in slope as slope protection structure.

3.Geocell can be used to build the support block structure

Properties of Geocell (Materials: HDPE)

Item Model	Height (mm)	Welding distance (mm)	Sheet thickness (mm)		Tensile yield strength of the cell (MPa)	Seam peel strength (N)
Item Model	Height (mm)	Welding distance (mm)	smooth	textured	Tensile yield strength of the cell (MPa)	Seam peel strength (N)
TGLG-50-400	50	400	1~1.1	1.4~1.5	20.0	500
TGLG-100-400	100	400	1~1.1	1.4~1.5	20.0	1000
TGLG-150-400	150	400	1~1.1	1.4~1.5	20.0	1500
TGLG-200-400	200	400	1~1.1	1.4~1.5	20.0	2000
TGLG-75-330	75	330	1~1.1	1.4~1.5	20.0	750
TGLG-100-330	100	330	1~1.1	1.4~1.5	20.0	1000
TGLG-150-330	150	330	1~1.1	1.4~1.5	20.0	1500
