Home > Products > Single Jet Water Meter > Single jet vane wheel dry type water meter
Single jet vane wheel dry type water meter
- 100000 Piece / Pieces per Month
- Shanghai Chongqing
- T/T
Product Details
Place of Origin: | Chongqing, China | Brand Name: | Galon | Model Number: | LXSC |
Product Description
Specifications
Application:--Measuring the volume of cold potable water passing through the pipeline.
Feature:
--Single-jet, dry-dial, free rotating register, small in size and light in weight;
--Magnetic drive, Resistance to exterior magnet interference,
--keep the reading clear in a long term service;
--Measuring accuracy conform to ISO 4064 class B standard..
--Available with different length on request. Available in hot water meter on request.
Working condition:
--Water temperature: 0.140 ( 0.190 for hot water meter)
--Water pressure : ≤1.0Mpa
Maximum Permissible Error:
(1) in the lower zone from qmin inclusive up to but excluding qt is ±5%
(2) in the upper zone from qt inclusive up to and including qs is ±2%
Hot water meter ±3%
MAIN TECHNICAL SPECIFICATIONS
Type | Size (mm) | Class |
qs
| qp |
qt
| qmin | Minimum Reading | Maximum Reading |
m3/h | L/h | m3 | ||||||
LXDG-15A | 15 | B | 3 | 1.5 | 120 | 30 | 0.00005 | 99,999 |
LXDG-20A | 20 | B | 5 | 2.5 | 200 | 50 | 0.00005 | 99,999 |
LXDG-25A | 25 | B | 7 | 3.5 | 280 | 70 | 0.00005 | 99,999 |
Type | Size (mm) | Length | Width | Height | Connecting Thread D | Weight (kg) |
mm | D | kg | ||||
LXSC-13D3 | 13 | 80/110 | 77 | 85 | G 3/4B | 0.6/0.7kg |
LXSC-20D3 | 20 | 130 | 77 | 85 | G 1B | 0.9 kg |
LXSC-25D3 | 25 | 160 | 77 | 92 | G1 1/4B | 1.47kg |
