Help CenterCable Assembly, SMA Female, Bulkhead to SMA Male With Cable Rg58, Jumper Cable, Pigtail
Related Products
-
Cable Assemblies Pigtail Cable rf ConnectorNegotiableMOQ: 10 Pieces -
SMA Female Bulkhead to IPX With 1.13 Cable, Pigtail, Cable AssemblyNegotiableMOQ: 10 Pieces
-
MCX Male Right Angle to SMA Female Bulkhead With Cable Rg316, Cable Assembly, Jumper, PigtailNegotiableMOQ: 50 Pieces
-
Cable Assembly, SMA Female to SMA Male With Cable Rg58, Jumper Cable, PigtailNegotiableMOQ: 50 Pieces
-
Communication Cable With ConnectorNegotiableMOQ: 10 Pieces
Description
Our company produces the cable packages are for the cable of line for the GSM, PCN and every communication system between the cabinet of machine and the cabinet of machine, between the antenna and the trunk cable, between the trunk cable and the cabinet of machine. Model of cable package, the variety is various. User may be according to the need, choice not of the came kind pattern connector of different model and diffevent the cable of length and model buy the cable package. May reduce the user himself load the cost to receive cable, guaranteed the usage mass.
According to customer demand for different types of cable assembly design customized products, so the quality of satisfaction with the Service class.
RG58
Construction Specification
|
Material |
Diameter(mm) |
1.Inner Conductor |
Tinned Copper |
19*0.18 |
2.Dielecric |
Solid Polyethlene |
2.95 |
3.Outer Conductor |
Tinned Copper Braid |
3.45 |
4.Jacket |
FVC |
4.95 |
Electrical Characteristics
Capacitance (pF/m) |
101.05 |
Impedance (ohm) |
50 |
Velocity (%) |
66 |
Shielding Effectiveness (>dB) |
70 |
Max.Oper.Voltage (VMS) |
1900 |
Operating Temp(°C) |
-20 to 80 |
Attenuation(Typical)
Frequency(MHz) |
Attenuation (>dB/100m) |
100 |
15.1 |
400 |
30.8 |
1000 |
50.2 |
About us
1.Company Introduction
Our company occupies 13500 m field, where the building area is 12000 m. There are more than 300 employees, 15 % of them are engineers and technicians. We are professional in designing, developing, producing and sales of radio frequency coaxial connectors.
According to the national and professional standards(GB&JS), we produce all kinds of RF coaxial connector:
SMA, SMB, SMC, BNC, TNC, N, 7/16(L29), 1.6/5.6(L9),MCX, MMCX, SSMA, SSMB, SSMC, SMZ, MC CARD(C2), 1.0/2.3(CC4), FME, UHF, MINI UHF, F, RCA, TAC etc.
And assembly of antenna, cable-package, audio and video connector, big specification connector of feeder line.
All kinds of adapter, impedance converter, fixed attenuator, termination loading, arrester.
All kinds of RF coaxial cable—SYV, SFF, RG, semi-rigid, etc.
This is our website:
2.Our workplace and professional team
3.Company Glories
4.Packing Details
Remark
If you are interesting in any of our products, please feel free to contact with me.
Quotation and pictures will be sent to your email within 24 hours after receive your specific enquires.
