Fakra H to IPEX coaxial cable RG178
- 20000 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card
- straight crc9 to sma female pigtail cable
- Golden plating crc9 right angle to sma female pigtail cable
- Coaxial Cable RP SMA male to N male adapter cable
- Coaxial Cable RP SMA male to N male RF adapter cable
- Coaxial Cable RP-SMA male to N male RF adapter cable
- Coaxial Cable N male to RP-SMA male Gold plating connector
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Yetnorson | Model Number: | YNX-RG58-SMA-ZJ01 |
Packaging Details
1pcs/PE bag for Fakra H to IPEX coaxial cable
Product Description
Specifications
Fakra H to IPEX coaxial cableDirectly factory manufacture
High quality competitive price
CE&ROHS
Fakra H to IPEX coaxial cable
SPEC | Structure of product | |||||
Connector Technical Characteristics | Frequency Range(MHZ) | 88Mhz-6Ghz | ||||
V.S.W.R | ≤1.50+0.02f | |||||
Impedance (Ω) | 50Ω | |||||
Insertion Loss | 0.6DB | |||||
Plating | gold plated | |||||
KV | 50±2 | |||||
Insulator | PTFE | |||||
RG Flexible Cables Technical Characteristics | Cable Type | RG58 | ||||
Center Conductor | 0.2 /Sliver Plated) | |||||
Insulation Dimensions | Ø 0.5±0.1mm PTFE | |||||
Screen Dimensions | Ø5 Sliver Plated | |||||
Jacket Dimensions | Ø5 | |||||
Nominal Impedance | 75Ω | |||||
Environment Specifications | Operation temperature | -55~+150°C | ||||
Operation Relative humidity | 55%~75% | |||||
Testing voltage of spark | 2000V | |||||
Testing voltage | 2000V | |||||
Attenuation(Typical)(dB/m) | 470MHz | 0.31dB | ||||
665 MHz | 0.52dB | |||||
712MHz | 059dB | |||||
800 MHz | 0.61dB | |||||
862 MHz | 0.65dB |
Refund & Replacement
1. We guarantee the product quality within one years .
2. If parts cannot work, we will return payment or replacement to you.
3. Any items must be returned in their original condition to qualify for a refund or replacement.
4. The buyer is responsible for all the shipping cost incurred.
Quality is essential to both of us, we believe that High quality, Low price,Mutual benefit will be good basis of our cooperation
Company Profile
Shenzhen Yetnorson Technology Co.,Ltd is one of professional antenna maker, which focus on GSM/CDMA/PHS/3G/4G antenna, 2.4GHz (wi-fi, wlan)/3.5GHz (wimax)/5.8GHz/wi-fi amplifier communication antenna serial(including: all direction, yagi antennas ,3G parabolic antennas, panel antenna, indoor antenna like : ceiling mount antenna, Wall Mount Antenna, desk antenna, double polar, rubber, bandwide, card mount serial antenna. We also provide DVB-T/DMB-T/CMMB moving digital TV antenna, low frenquency antenna: 315MHz/433MHz wi-fi digital /wi-fi control /wi-fi wrote water meter/electricity meter antenna, GPS guide antenna, communicate parts, connector and so on. At present, Shenzhen Yetnorson Technology Co.,Lth.has developed more than 100 styles of antenna, with wi-fi internet, wi-fi electronic control, wi-fi end, wi-fi public telephone, wi-fi digital pass, wi-fi Satilla position, wi-fi Radio broadcasting communication field.
We offer antennas with good quality and good price. And we are cooperating with several overseas clients from all over the world. Please support us. Thank you very much!
