LREC6220PF
PCIe x1 1000Base-SX Intel Processors 1G SC Port Fiber Lan Card (Intel 82575EB Based)
Industry-leading performance
The LREC6220PF Gigabit Ethernet Fiber Lan Card solution is designed for high-end appliances. The performance is optimized so that system I/O is not the bottleneck in high- performance networking applications.
Reliability, Availability, Serviceability
The LREC6220PF enables fault-tolerant via teaming. Traffic from the failed port is routed through up to seven other members of the team.
LR-LINK LREC6220PF Gigabit Ethernet Fiber Lan Card adapters have an integrated hardware acceleration that performs TCP/UDP/IP checksum offload and TCP segmentation. The host processing offloads accelerators frees CPU for application processing.
LREC6220PF Fiber Lan Card is single SC connector fiber adapter. The Intel 82575EB server controller has the high performance, high stable, high quality and best compatibility. It can compatible all the brand computers and fiber switches in market. It is the good solution for the high-performance FTTD applications.
Server class reliability, availability and performance features
Link Aggregation and Load Balancing
Switch dependent: 802.3ad (LACP), Generic Trunking (GEC / FEC)
Switch and NIC Independent
Failover
Priority queuing 802.1p layer 2 priority encoding
Virtual LANs 802.1q VLAN tagging
Jumbo Frame (16KB)
802.x flow control
Statistics for SNMP MIB II, Ethernet like MIB, and Ethernet MIB (802.3z, Clause 30)
LEDs indicators for link/Activity/Speed status
Support PXE
Support WOL (Wake-on-Lan)
PCIe x1 1000Base-SX Intel Processors 1G SC Port Fiber Lan Card (Intel 82575EB Based)
M/N |
Description |
Notes |
LREC6220PF-SFP |
PCIe x1 1000Base SFP Port Fiber NIC |
SFP connection, do not contain the fiber module |
LREC6220PF |
PCIe x1 1000Base-SX SC Port MM Fiber NIC |
1.25Gbps,850nm, 275m at 62.5 µm; 550m at 50 µm |
LREC6220PF-LX |
PCIe x1 1000Base-LX SC Port SM Fiber NIC |
1.25Gbps,1310nm, 20Km at 9 µm; |
LRGP8512-X5ATL |
1.25Gbps SFP multi-mode Transceiver |
1.25Gbps,850nm, 275m at 62.5 µm; 550m at 50 µm |
LRGP1312-20ATL |
1.25Gbps SFP Single-mode Transceiver |
1.25Gbps,1310nm, 20Km at 9 µm; |
