PCB or LED Conformal Coating Machine China Supplier TH-2004AE

PCB or LED Conformal Coating Machine China Supplier TH-2004AE thumbnail-1
PCB or LED Conformal Coating Machine China Supplier TH-2004AE photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
TianHao Dispensing
Model Number:
TH-2004AE
Contact Supplier Request Quote Chat Now
Cixi Tianhao Electric Technic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name TianHao Dispensing
Model Number TH-2004AE
Condition New
After-sales Service Provided Overseas service center available



Model:



TH-2004AE   PCB or LED Conformal Coating machine  china supplier





Model:

TH-2004AE Floor-type design and gantry-style three-dimensional Transfer institutions may apply for a larger volume of product processing, pick and place parts more convenient, processed faster and providing greater stability.Dedicated to glass glue, high-viscosity glue sealant, polyurethane, silicone and other packaging.

PCB or LED Conformal Coating machine china supplier TH-2004AE



Sales Points/Focus

1.High viscosity gel technology, equipment, rapid emptying and transient back to the lock function, the glue can be totally and easily whipped off.

2. the Z-axis have brake motors, greatly increasing the stability of the equipment and its motion accuracy.when that 6kg maximum z axis load will remain in a upper position after switching off the power.

3. Tianhao graphics editing software can import such as NC, AI, DXF, JPG, BMP and other format files

4. Professional dispensing software based entirely on the dispensing process development.

5. PLC Controller, Easy to program - Dedicated dispensing software eliminates the need for complex robot language programming.

6. Increase the parameters display with programmer, which will provide you more intuitive operation.

7. Each axis with 2 linear guide rail will provide you better stability.

8. Simplifies robot and master control systems, high speed capabilities, large work envelope.

9. As customer production require add the I / O interface, easy add other device for the equipment

10. A XY work range increased of 20MM.

11. Single machine can operate.Avoid staff misuse, or change has set a good program

12.XY/Z Maximum Load 15KGS/6KGS

13.Repeatability: +-0.01 mm/ axis,3 axis synchronous work get +-0.01 mm/axis, other competitors no possible 3 axis get this precision at same time.

14.Transmission:new timing belt/precision linear Guides

15.Drive System: new precision micro-stepper motor

16.Single machine can operate.Avoid staff misuse, or change has set a good program

17.Flexible power supply design for overseas use.





Main specification



ITEM

TH-2004AE

X/Y/Zworking range

500 x 500 x 100mm

XY/ZMaximum Load

30 kg / 15 kg

XY/Z  Speed

1000/300mm/Axis

Repeatability

±0.015mm/Axis

Resolution

0.001mm/Axis

Edit programs

Rocker/mouse/Keyboard

Positing

Electric "+"target confirm place

Imaging

advance of CCD image location

Data memory capacity

No limit HD

Operation System

Windows XP

Control Method

PC control, LCD display

Drive System

Panasonic servo motor

Transmission

Timing Belt/PMI Linear guide

Limit device

Omron Photoelectric sensor limit protection

Patterns

Lines, Circles, Arcs, Continuous Paths, 3D linear interpolation

Power Supply

AC 220V  50/60Hz

Working Temperature

0 ~40 °C

Relative Humidity

20~90% (no condensation)

Dimensions (WxDxH)

1000 x 1000 x 1650mm

Weight

360Kg





Complete accessories dispensing kit:





NO.

Name

Qty

1

Robot

1set

2

Computer

1set

3

LCD display

1pcs

4

Mouse/ Mouse mat

1set

5

keyboard

1pcs

6

control rocker

1pcs

7

Adjusting pressure valve( filter)

1set

8

Tank

2pcs

9

Blue “U” hardware key

That’s very important part for machine

1pcs

10

Camera /camera power line

1set

11

Tool

1 set

12

Image  line

1pcs

13

Robot power line

1pcs

14

Computer power line

1pcs

15

Backup power

1set

16

Air tube

1pcs

17

Tool/Tool box

1set

18

socket

2pcs

19

Warrary card

1set

20

Machinery certificate(CE)

1pcs

21

Manual operation

1pcs





Package:

Items per Carton:

1 Units / Carton

Package Measurements:



1000x 1000x 1650mm



Gross Weight:



360Kg





PCB or LED Conformal Coating machine china supplier TH-2004AE



Delivery in 30 workday after received your payment

Shipping ways by sea or Air

Loading port:Ningbo or shanghai





Our Service: Your satisfactory, our pursuit!



1,Your inquiry will be replied in 24 hours.



2,Offer free spare parts and service within one year of warranty,



3,Technology Support Provide Demo operation video for training; If you have time,



welcome to our company, Will arrange engineers to show you the operation.



4, Professional after-sales service team;



5,Give great discount to AGENCY to ensure agents profit.



Our product can help you to achieve the goal :



  • Increase production efficiency
  • Promotion processing precision control
  • Improve product quality
  • lower production costs, reduce rejected product
  • Eliminate material waste





Quality guarantee

We provide 1 years warranty of product and shipment with one set fitting to you

Related Poduction



Our advantages:



1. Original Manufacturer/factory



2. High reputation around the china



3. 10 years experience of glue dispensing machine



4. Best quality and good work



5. High grade components



6. Special dispensing software, both Chinese and English interface



7. Professional service and technology support



8. All models with CE approved;



9. OEM services accepted



Our product:



  • 4 Axis dispensing robot.XYZ dispensing robots- for full automated and high precision ,high efficiency production processes control
  • Dispenser.mix/meter dispensing system - for manual assembly processes
  • Threadlocking adhesives coating machine-suitable for thread coating processes
  • Rotary table Dispensing machine- for dispensing circular beads on circular, semi-circular, oval, product
  • Valve, tank-for automated production lines
  • Highest quality dispensing tips ,syringe barrels
  • Other disposable components



Customizable:



1.Input /Oput singal



 workrange



3.add pick and place function





PCB or LED Conformal Coating machine china supplier TH-2004AEPCB or LED Conformal Coating machine china supplier TH-2004AE

PCB or LED Conformal Coating machine china supplier TH-2004AE
