vibrating fluid-bed drier

Specifications

It is widely used for operation of drying,cooling and damp increasing (or carry out at the same time) for powder or granule.

Description:



Raw material is fed into the machine from the inlet and moves forward continuously along with the level of fluidized-bed under the action of vibration. The hot air passes through fluidized-bed and carries out heat exchange with damp raw material. Then the damp air is exhausted out through the cyclone separator and deduster. The dry raw material is discharged through discharge outlet.



Features:



1. Adopt vibration motor, it is smooth in runing and convenient in maintanance. The noise is low and the working life is long.



2. The state of fluidization is uniform, without the phenomenon of gap and blowing out. The uniform drying and cooling product can be got.



3. It is good in adjustment and wide in the field of application. The thickness of raw material and the speed of raw material to be moved inside the machine and the change of vibration range can be stepless.



4. The damage to the surface of raw material is small. So it can be used for raw materials that are easily to be broken. If the granule is not normal, the effect of process can not be effected.



5. The structure is fully seal, it is effective to prevent from cross infection between material and air. The operating environment is clean.



6. High mechanical and thermal efficiency and good effect of energy saving. Compared with ordinary drying equipment, it can save 30-60% energy.



Application:



It is suitable for drying and cooling powder or granule in the fields of chemistry, pharmacy, foodstuff and mineral. Such as citric acid, monosodium glutamate, borax, ammonium sulphate, compund fertilizer, bean, lees, seed, slag and sugar.



Technical Parameter:



specification	fluid-bed size		overall size			power of motor (kw)	weight (kg)
	A1	A2	A	B	C
3× 30	300	3000	890	3505	1830	0.5 × 2	1240
3× 45	300	4500	1116	5005	1830	0.75× 2	1570
6× 45	600	4500	1286	5005	1904	1.1× 2	1967
6× 60	600	6000	1286	6510	1940	1.1× 2	2743
6× 75	600	7500	1286	8010	1940	1.1× 2	2886
9× 60	900	6000	1830	6510	2110	2.2× 2	3540
9× 75	900	7500	1830	8010	2110	2.2× 2	4219
12× 75	1200	7500	2400	8010	2450	3× 2	5223
15× 75	1500	7500	2850	8010	2570	4× 2	6426
18× 80	1800	8000	3250	8520	3100	5.5× 2	8600



 Product Details:
