Specifications
low cost, small size, ultra-high-power, low harmonic ASK transmitter moduleSTX882 is a low cost, small size, ultra-high-power, low harmonic ASK transmitter module. Has high stability and high cost, at 3.6V power to achieve 50mW, is currently on the market under the same voltage transmit power ASK transmitter module. The module can be connected to the microcontroller directly. So it is more convenient for user developing wireless products.
Specifications/Datasheet:(Pleae click)
Parameter |
Min. |
Typ. |
Max |
Unit |
Conditions |
Operation conditions | |||||
Supply Voltage |
1.2 |
3.0 |
6 |
V |
|
Operating Temperature Range |
-20 |
25 |
70 |
°C |
|
Current consumption | |||||
TX current |
20 |
mA |
@5V,13dBm |
||
Sleep Current |
≤0.01 |
uA |
@DATA As Low level |
||
RF parameters | |||||
Frequency Range |
433.82 |
433.92 |
434.02 |
MHZ |
@433MHZ |
314.9 |
315 |
315.1 |
MHZ |
@315MHZ |
|
RF power |
12 |
13 |
13.5 |
dBm |
@2.4V |
14 |
15 |
15.5 |
dBm |
@3V |
|
19.5 |
20 |
20.5 |
dBm |
@5V |
|
Air rate |
0.1 |
9.6 |
Kbps |
||
Features:
*Frequency Range: 433/315 MHZ
*ASK modulation mode
*Small volume low self radiation
*High-power long-range
*Frequency stability
*Various international testing standards
Application:
*Remote door
*Wireless security alarm
*Wireless industrial control
*Wireless data transmission
