Loader machine LiuGong CLG835 tractor with loader
We have been long-term involving in providing high performance-cost ratio products.
Looking forward to your sincere cooperation.
Specifications
LIUGONG Wheel Loader CLG835 (3ton)
1.Rated load: 3000kg
2.Bucket capacity: 1.5~2.0m3
3.Engine:6BT5.9 (92
|
LIUGONG CLG835 Wheel Loader 3ton 1.7m3
YUCHAI CHINESE ZF GEARBOX, A/C, PILOT CONTROL, FOPS/ROPS CABIN, 3.0CBM BUCKET
Engine | |
Model |
Yuchai |
Rated load |
3000Kg |
Operating weight |
10200Kg |
Rated bucket capacity |
1.7m3 |
Max. breakout force |
90kN |
Max. dump clearance |
3160mm |
Dump reach |
1050mm |
Dump angle at any position |
≥45° |
Digging depth(with bucket bottom horizontal) |
212mm |
|
Min. turning radius | |
-----Outside of bucket |
5600mm |
-----Outside of rear wheel |
5205mm |
Oscillating angle of rear axle |
±11° |
Lifting time of bucket |
≤5.8s |
Lowering time of bucket |
≤3.77s |
Dumping time |
≤1.43s |
|
Working Equipment | |
Model of oil pump |
CBGj2100 |
System pressure |
16Mpa |
Model of multi-way directional valve |
DF25.2C |
Pilot valve |
DJS2-UX/UU |
|
Axle And Tyre | |
Type of main reducer |
Spiral bevel gear, single stage |
Gear ratio of main reducer |
5.286 |
Type of final reducer |
Single stage planetary |
Gear ratio of final reducer |
4.75 |
total ratio |
25.1 |
Max. tractive force |
93.5kN |
Tyre size |
17.5-25 |
|
Transmission System | |
Torque Converter | |
Type |
3-elements,single stage(Shantui) |
Torque ratio |
3.1 |
Cooling type |
Pressure oil circulating |
Gear box | |
Type |
Power shift(China advance) |
Gear shifts(Forward/Reverse) |
F4/R2 |
Traveling speed(Km/h) | |
Forward/Reverse |
7.7/9.5 |
Forward/Reverse |
13/18 |
Forward |
25 |
Forward |
40 |
|
Braking System | |
Service brake |
Air over oil activate 4 wheel brake with capliar disc brake |
Air pressure |
0.68Mpa |
Parking brake |
Draper -type soft axle control |
|
Steering System | |
Type |
Middle articulated frame. Co-axis flow amp.steering |
Model of steering pump |
CBGj2050 |
Model of redirector |
BZZ5-E400C |
System pressure |
14MPa |
Articulated steering angle |
38±1°(L/R) |
|
Dimensions | |
Length(with bucket on ground) |
7135mm |
Width(to outside of wheels) |
2350mm |
Height(To the top of the cab) |
3300mm |
Bucket width |
2440mm |
Wheel base |
2750mm |
Tread |
2050mm |
Ground clearance |
395mm |
|
Service Capacities | |
Fuel tank |
140L |
