2000kg mini wheel loader for sale
- 2000 Set / Sets per Month
- tianjin
- T/T
Product Details
Condition: | New | Brand Name: | mini wheel loader | Model Number: | wheel loader |
Place of Origin: | Shandong, China | Type: | Mini Loader | Moving Type: | Wheel Loader |
Dimension(Long * Breadth * High): | 5900*2200*2800(mm) | Rated Load: | 2000kgs | Certification: | iso ,ce |
Warranty: | 12 month | After-sales Service Provided: | Overseas third-party support available |
Product Description
Features of 2015 hot sale 2000kg CE mini wheel loader :
* 75KW Cummins engine for option.
* CE approved mini front end loader.
* Joystick & pilot control, quick release, various optional tools.
* Seal and heater cab, A/C.
* Adjustable steering wheel, adjustable seat with safe belt.
* New preheater on engine,easy to start when it is very cold.
Performance | 1 | rated loading | 2000kg |
2 | Operation weight | 5800kg | |
3 | rated bucket capacity | 1.1-1.3m3 | |
4 | maximum tractive force | ≥54KN | |
5 | maximum breakout force | ≥45.4KN | |
6 | maximum grade ability | 30 | |
7 | maximum dump height | 2800mm/3100mm/3500mm/4200mm | |
8 | dump distance | 900mm/1000mm/1300 | |
9 | overall dimension (L×W×H) | 5900×2200×2800mm | |
10 | minimum turning radius | 5251mm | |
Engine | 11 | model | WeiChai /Yuchai /cummins |
12 | type | Vertical, in-line, water cooled, 4-stroke diesel engine | |
13 | No. of cylinder-bore/stroke | 4—105×125mm | |
14 | rated power | 60kw—2200r/min | |
15 | maximum torque | 270N.m | |
16 | min fuel-consume ratio | ≤243g/kw.h | |
Transmission system | 17 | torque converter | YJ 280 |
18 | gearbox mode | Countershaft power-shift | |
19 | gear shift | 2 forward shift 2 reverse shift | |
20 | maximum speed | 24km/h | |
Drive axles | 21 | main reducing spiral | Circular Arc Bevel gear, single stage |
22 | decelerating mode | Single stage planetary type | |
23 | wheel base (mm) | 2400mm | |
24 | Track base(mm) | 1640mm | |
25 | Mini base to the ground | 310mm | |
Hydraulic system | 26 | system working pressure | 16MPa |
27 | boom lifting time | 4.8s±0.2s | |
28 | total time | 9.2s±0.5s | |
29 | fuel tank capacity | 80L | |
30 | function of leveling automatically | yes | |
Brake system | 31 | service brake | air assist disc brake on 4 wheels |
32 | parking brake | flexible shaft operated external drum | |
Tyre | 33 | type specification | 16/70—20 / 16/70-24 |
34 | front tyre pressure | 0.22Mpa | |
35 | rear tyre pressure | 0.18Mpa |
