SHANTUI SL50W-2 Wheel Loader

SHANTUI SL50W-2 Wheel Loader thumbnail-1
SHANTUI SL50W-2 Wheel Loader photo-1
US$ 50,000 - 100,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
SHANTUI SL50W wheel loader
Model Number:
SL50W
Contact Supplier Request Quote Chat Now
Jinan Kunda Automobile Sales Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin shanghai qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Brand Name SHANTUI SL50W wheel loader
Model Number SL50W
Place of Origin Shandong, China
Type Front Loader
Moving Type Wheel Loader
Dimension(Long * Breadth * High) 5500*1960*2800
Rated Load 1.6
Certification CE CCC
Warranty 1year
After-sales Service Provided Overseas third-party support available

china wheeled loaders 985 wheel loader for sale

four wheel drive wheel loader with ZF rear axle optional, joystick, A/C, and rock bucket



Wheeled loaders features 1. The wheeled loaders

uses a hydro-mechanical transmission which can make full use of engine power and can have automatic variable transmission according to the external resistance. the wheel loader avoids power failure of the engine due to the suddenly increased external load. The wheel loader can absorb and eliminate the vibration and impact of external load on engine. It protects the drive system and engine, increases the service life, facilitates the operation and achieves higher economical and production efficiency. 2. The wheeled loaders uses the central articulated frame and load sensing hydraulic steering gear. The machine can achieveshort turning radius and superposition of the front and rear tracks upon turning (this will ensure safe driving). The wheel loader has the advantages of easy operation on narrow site, flexible operation, safety, convenient maintenance and so on. 3. The wheel loader uses four-wheel drive, low-pressure wide base off-road tires and an oscillating rear axle, so it has sound off-road performance, good trafficability and larger traction. 4. The wheeled loaders is equipped with a single-pipe type hydraulic four-wheel brake. 5. The wheeled loaders has a fully enclosed cab and the seats have the functions of vibration reduction and easy adjustment. The machine offers the driver a comfortable drive and wide view.



Wheel loader parameters



5ton wheel loader



Performance

1

rated load

5000kg

2

overall weight

17100kg

3

rated bucket capacity

3m3

4

maximum tractive force

152KN

5

maximum breakout force

≥170KN

6

maximum grade ability

30°C

7

maximum dump height

3150mm

8

maximum dump reach

1250mm

9

overall dimension (L×W×H)

7920×3050×3400mm

10

minimum turning radius

6640mm

wheeled loaders Engine

11

model

Weichai Steyr WD615G.220

12

type

lnline water cooling dry cylinder injection

13

No. of cylinder-bore/stroke

6-126×130mm

14

rated power

162kw--2400r/min

15

maximum torque

860N.m

16

min fuel-consume ratio

≤215g/kw.h

Transmission system

17

torque converter

YJ375

18

gearbox mode

Power shift normally engaged straight gear

19

gear shift

4 forward shift

8/15/23/38

4 reverse shift

8/15/23/38

20

maximum speed

38km/h

Drive axles

21

main reducing spiral

bevel gear grade 1reduction

22

decelerating mode

planetary reduction,grade 1

23

wheel base (mm)

3200mm

24

wheel tread

2250mm

25

minimum ground clearance

450mm

Hydraulic system

26

system working pressure

18MPa

27

boom lifting time

5.95±0.2s

28

total time

10.95±0.5s

29

fuel tank capacity

300L

30

function of leveling automatically

yes



Brake system

31

service brake

air over hydraulic disc brake on 4 wheels

32

parking brake

manual parking brake

Tyre

33

type specification

23.5-25

34

front tyre pressure

0.4Mpa

35

rear tyre pressure

0.35Mpa

 SHANTUI SL50W-2 wheel loaderSHANTUI SL50W-2 wheel loaderSHANTUI SL50W-2 wheel loaderSHANTUI SL50W-2 wheel loader
