High Quality High Dbi External Vehicle Combo Gps/gsm/wifi Antenna With RG174 SMA Connector

Bubble envelope,Carton packaging or as request of high quality high dbi external vehicle combo gps/gsm/wifi antenna with RG174 SMA connector

                                           high quality high dbi external vehicle

                         combo gps/gsm/wifi antenna with RG174 SMA connector

      Welcome to Shenzhen Yetnorson technology Co., LTD.

The advantage of high quality high dbi external vehicle combo gps/gsm/wifi antenna with RG174 SMA connector

1,rich experience , proven technique
2,low price and high gain
3,wider frequency

Specifications of high quality high dbi external vehicle combo gps/gsm/wifi antenna with RG174 SMA connector

GPS antenna part

• Center Frequency:1575.42MHz
• Polarization: RHCP (right hand circular polarization)
• LNA Gain: 28dB typical
• Noise figure: 1.5 maximum
• Bandwidth: 10MHz
• VSWR: 2.0 maximum
• Impedance:50 Ohms
• Power consumption: 2.7 to 5.5V DC/28mA
• Cable and connector: 3m RG-174 with RP SMA male connector
• Operating temperature: -35 to +85 degrees Celsius
• Storage temperature: -40 to +95 degrees Celsius
• Dimensions-mm: 80*14

 GSM antenna part

• Frequency: 890-960MHz/ 1710-1880MHz
• Polarization: vertical
• Gain: 3dBi
• VSWR: 2.0 maximum
• Impedance: 50 Ohms
• Power handling capacity: 10W maximum
• Cable and connector: 3M RG174 with SMA male connector
• Operating temperature: -35 to +85 degrees Celsius
• Storage temperature: -40 to +95 degrees Celsius
• Dimension-mm: 80*14

The appearance of high quality high dbi external vehicle combo gps/gsm/wifi antenna with RG174 SMA connector

Test pattern :

Each products are through strict test

GPSM Antenna     GPS GSM Anten    GPS GSM Antenna

 1. We can guarantee the product quality within one years

 2. If parts cannot work, we will return payment or replacement to you.

 3. Any items must be returned in their original condition to qualify for a refund or replacement.

 4. The buyer is responsible for all the shipping cost incurred

       Shenzhen Yetnorson technology Co., LTD. as one of the emerging high-tech enterprise.Who is one of the leader who is engaged in the antenna products .custom service, R&D, design,Our main prooducts at GSM/GPS/CDMA/DVB-T/DMB-T/DAB-T/ISDB /PHS / 3 G / 4 G /5.8G, 2.4 GHz (WIFI, wireless local-area network (wlan)-/ 3.5 GHz wimax (5.8 GHz) / wireless spread spectrum communication series

1,Q:what is you brand ?
A: Yetnorson  antennas

2,Q:how can i get the sample ?
A: if you need sample to test ,please pay for the shipping cost ,there we can free for one sample to you

3,Q: how much the shipping cost will be for sample ?
A :The depend on the weight and packing size you are

4, Q :how can i get the price list ?
A :please send the email and order information for us , so we can give the latest price for you

5.Q:Can you give me the deliver time?

A: Delivery time is approx. 14 to 25 business days (excluded Saturday & Sunday, Public Holiday) to most US/UK/AU destinations
1) Australia - 7-14 working days
2)UK/ Canada - 14-21 working days
3)Europe & Ireland - 18-24 working days
4)Brazil/ South America - 30-40 working days
5)Russian Federation:30-50 working days,we suggest you choose hk post
