Best Selling Product Factory Price Ceramic Active Combined Gsm Gps Antenna Receiver

Best Selling Product Factory Price Ceramic Active Combined Gsm Gps Antenna Receiver thumbnail-1
Best Selling Product Factory Price Ceramic Active Combined Gsm Gps Antenna Receiver thumbnail-2
Best Selling Product Factory Price Ceramic Active Combined Gsm Gps Antenna Receiver thumbnail-3
Best Selling Product Factory Price Ceramic Active Combined Gsm Gps Antenna Receiver photo-1
Best Selling Product Factory Price Ceramic Active Combined Gsm Gps Antenna Receiver photo-2
Best Selling Product Factory Price Ceramic Active Combined Gsm Gps Antenna Receiver photo-3
US$ 2 - 6 MOQ: 1 Piece
Key Specifications
Get Latest Price
Type:
Gps Antenna
Use:
Automotive
Screen Size:
7 inch
Contact Supplier Request Quote Chat Now
Shenzhen Yetnorson Technology Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Gps Antenna
Use Automotive
Screen Size 7 inch
Function Other, antenna
Place of Origin Guangdong, China
Brand Name yetnorson
Model Number YNX-GPS GSM antenna-0059
Warranty 3 Years

    best selling product factory price ceramic active combined gsm gps antenna receiver

      Welcome to Shenzhen Yetnorson technology Co., LTD.

The advantage of best selling product factory price ceramic active combined gsm gps antenna receiver

1,rich experience , proven technique
2,low price and high gain
3,wider frequency

Product Description



Specifications of best selling product factory price ceramic active combined gsm gps antenna receiver

GPS antenna part

  • Center Frequency:1575.42MHz
  • Polarization: RHCP (right hand circular polarization)
  • LNA Gain: 28dB typical
  • Noise figure: 1.5 maximum
  • Bandwidth: 10MHz
  • VSWR: 2.0 maximum
  • Impedance:50 Ohms
  • Power consumption: 2.7 to 5.5V DC/28mA
  • Cable and connector: 3m RG-174 with RP SMA male connector
  • Operating temperature: -35 to +85 degrees Celsius
  • Storage temperature: -40 to +95 degrees Celsius
  • Dimensions-mm: 80*14

 GSM antenna part

  • Frequency: 890-960MHz/ 1710-1880MHz
  • Polarization: vertical
  • Gain: 3dBi
  • VSWR: 2.0 maximum
  • Impedance: 50 Ohms
  • Power handling capacity: 10W maximum
  • Cable and connector: 3M RG174 with SMA male connector
  • Operating temperature: -35 to +85 degrees Celsius
  • Storage temperature: -40 to +95 degrees Celsius
  • Dimension-mm: 80*14

The appearance of  best selling product factory price ceramic active combined gsm gps antenna receiver

best selling product factory price ceramic active combined gsm gps antenna receiverbest selling product factory price ceramic active combined gsm gps antenna receiverbest selling product factory price ceramic active combined gsm gps antenna receiver



Test pattern :

Each products are through strict test







GPSM Antenna     GPS GSM Anten    GPS GSM Antenna

Payment&Shipment



Packaging & Shipping





Our Services



 1. We can guarantee the product quality within one years

 2. If parts cannot work, we will return payment or replacement to you.

 3. Any items must be returned in their original condition to qualify for a refund or replacement.

 4. The buyer is responsible for all the shipping cost incurred

Company Information



       Shenzhen Yetnorson technology Co., LTD. as one of the emerging high-tech enterprise.Who is one of the leader who is engaged in the antenna products .custom service, R&D, design,Our main prooducts at GSM/GPS/CDMA/DVB-T/DMB-T/DAB-T/ISDB /PHS / 3 G / 4 G /5.8G, 2.4 GHz (WIFI, wireless local-area network (wlan)-/ 3.5 GHz wimax (5.8 GHz) / wireless spread spectrum communication series

Certificate



FAQ



1,Q:what is you brand ?
A: Yetnorson  antennas

2,Q:how can i get the sample ?
A: if you need sample to test ,please pay for the shipping cost ,there we can free for one sample to you


3,Q: how much the shipping cost will be for sample ?
A :The depend on the weight and packing size you are

4, Q :how can i get the price list ?
A :please send the email and order information for us , so we can give the latest price for you



5.Q:Can you give me the deliver time?

A: Delivery time is approx. 14 to 25 business days (excluded Saturday & Sunday, Public Holiday) to most US/UK/AU destinations
1) Australia - 7-14 working days
2)UK/ Canada - 14-21 working days
3)Europe & Ireland - 18-24 working days
4)Brazil/ South America - 30-40 working days
5)Russian Federation:30-50 working days,we suggest you choose hk post
