Diesel Transport 23 m3 Oil Tank Truck for Sales

Name: Diesel Transport 23 m3 Oil Tank Truck for Sales
Brand: SINOTRUK
SKU: 115335461
Availability: InStock

US$ 40,000 - 50,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Storage:

Oil

Drive Wheel:

8x4

Jinan Kunda Automobile Sales Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Storage Oil

Drive Wheel 8x4

Horsepower 251 - 350hp

Transmission Type Manual

Fuel Type Diesel

Tank Volume 15001 - 30000L

Engine Capacity 9.726L

Dimensions (L x W x H) (mm) 11900*2496*3025

Brand Name SINOTRUK

Place of Origin Shandong, China

Model Number JYJ5312GJY

Gross Vehicle Weight 31000

Product Description

Diesel transport 23 m3 oil tank truck for sales

GVW31000kg Driving Type 8x4

Chassis Model		ZZ1317N4641W
Engine	Model	WD615.69	WD615.47
	Horsepower	336	371
	Maximum output Kw/r/min	196/2200	213/2200
	Maximum torque N.m/r/min	1100/1100-1600	1160/1100-1600
	Type	6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection
	Bore x Stroke	126x130mm
	Valve	2
	Displacement	9.726L
	Make SINOTRUCK (CNHTC), Euro II emission standard, Thermostat with 80℃ opening begin, Rigid fan

Cab	SINOTRUK HW76 lengthen cab, single bunk
Clutch	SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance
Transmission	SINOTRUK HW19710 transmission ,10 forward and 2 reverse
Front Axle	SINOTRUK HF7 Front Axle
Steering	German ZF8098 Steering Gear Box ,hydraulic steering with power assistance,Ratio:22.2-26.2
Rear Axles	ST16 drive axle
Brake System	Service brake:dual circuit compressed air brake Parking brake (emergency brake):spring energy,compressed air operating on rear wheels Auxiliary brake:engine exhaust valve brake
Tyres	295/80R22.5 tyre with 1 spare tyre Option:12.00R20 radial tyre
Oil Tank	400L
Delivery date	Within 50 working-days after receipt advance
Weight in kg	Gross vehicle weight 31000 Front axle loading capacity 7000 Rear axles loading capacity 16000
Performance	Maximum drving speed (km/h) 90 Fuel consumption (1/100 km) 38
Packing	Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity.
