Specifications
bluetooth gps glonass antenna1, Frequency 1602MHz/1575mhz
2, Low MOQ
3, Connector :sma
4.CE,FCC,ROHs
Manufacturer Supply 29dBi Antenna Bluetooth 1602MHz Glonass Antenna External Bluetooth GPS Glonass Antenna
Application :
1.For Glonass system,passive antenna,made of Ceramic Microstrip Substrate
2. Compact Size, Light Weight, Low Profile, Easy to Assemble and Hide
3. The high gain LNA is made of low noise microwave components to ensure the sensibility of the system.
| Frequency (MHz) | 1602mhz/1575mhz |
| Bandwidth (MHz) | 6MHZ |
| Gain (dBi) | 29dB±3dB |
| Input Impendence (Ω) | 50 |
| V.S.W.R | ≤1.7 |
| Consumption Electric | <10mA |
| Polarization Intensity | R.H.C.P |
| Supply Voltage | DC3.3~5.0V |
| The Sound Coefficient | ≤1.5dB |
| Axial Ratio | 3Db |
| Max Input Power (w) | 50 |
| Operating Temperature | -40°C~+85°C |
| Storing Temperature | -40°C~+90°C |
| Cable length (mm) | 3000 |
| Connector Type | Fakra |
| Radome Color | Black |
| Weight (g) | 69 |
| Fixed Mode | Magnet |
Refund & Replacement
1. We can guarantee the product quality within one years .
2. If parts cannot work, we will return payment or replacement to you.
3. Any items must be returned in their original condition to qualify for a refund or replacement.
4. The buyer is responsible for all the shipping cost incurred.
Quality is essential to both of us, we believe that High quality, Low price,Mutual benefit will be good basis of our cooperation!!!
