Hot Selling 29dBi Antenna Micro GPS Signal Extender Antenna High Gain Micro GPS Glonass Antenna
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Factory Directly Supply GPS+Glonass AP Terminal Antenna External GPS Glonass Patch Antenna
-
High Power 29dBi Antenna 1602MHz Glonass Dipole Antenna External 1602mhz Glonass Antenna With Rg174 Cable
-
Manufacturer Supply 29dBi Antenna 1602MHz Glonass Terminal Antenna High Gain 1602mhz GPS Glonass Antenna With Rg174 Cable
-
High Power 29dbi Antenna GPS+Glonass Omni Antenna Indoor GPS+Glonass Car Antenna With Rg174 Cable
-
Manufacturer Supply Glonass Terminal GPS Antenna External GPS+Glonass Car Active Antenna With SMA Connector
-
(Manufactory)Free Sample Auto Gps Glonass Active Car Antenna
Product Details
| Type | Gps Antenna | Use | Automotive | |
| Screen Size | 2.5 inch | Function | Touch Screen, Bluetooth-enabled, Mp3/Mp4, DVD/VCD, Photo Viewer, Radio Tuner | |
| Place of Origin | Guangdong, China | Brand Name | Yetnorson | |
| Model Number | YNX-TLB-1897-micro gps glonass antenna | Warranty | 2 Years |
One product with one PE bag packaging of micro gps glonass antenna
Product Description
Specifications
micro gps glonass antenna1, Frequency 1602MHz/1575mhz
2, Low MOQ
3, Connector :sma
4.CE,FCC,ROHs
Hot Selling 29dBi Antenna Micro GPS Signal Extender Antenna High Gain Micro GPS Glonass Antenna
Application :
1.For Glonass system,passive antenna,made of Ceramic Microstrip Substrate
2. Compact Size, Light Weight, Low Profile, Easy to Assemble and Hide
3. The high gain LNA is made of low noise microwave components to ensure the sensibility of the system.
| Frequency (MHz) | 1602mhz/1575mhz |
| Bandwidth (MHz) | 6MHZ |
| Gain (dBi) | 29dB±3dB |
| Input Impendence (Ω) | 50 |
| V.S.W.R | ≤1.7 |
| Consumption Electric | <10mA |
| Polarization Intensity | R.H.C.P |
| Supply Voltage | DC3.3~5.0V |
| The Sound Coefficient | ≤1.5dB |
| Axial Ratio | 3Db |
| Max Input Power (w) | 50 |
| Operating Temperature | -40°C~+85°C |
| Storing Temperature | -40°C~+90°C |
| Cable length (mm) | 3000 |
| Connector Type | Fakra |
| Radome Color | Black |
| Weight (g) | 69 |
| Fixed Mode | Magnet |
