CQ6125Vx550 Mini Lathe Machine

Name: CQ6125Vx550 Mini Lathe Machine
Brand: mini lathe machine
SKU: 115322131
Availability: InStock

US$ 800 - 1,000 MOQ: 5 Sets

Key Specifications

Condition:

New

Type:

Horizontal

CNC or Not:

Normal

Shanghai Zhong Jing Imp. & Exp. Corporation

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

CNC or Not Normal

Automatic Grade Manual

Max. Swing Diameter 250mm

Place of Origin Shanghai, China

Brand Name mini lathe machine

Model Number CQ6125Vx550

Voltage 110-380V

Power(W) 750W

Dimension(L*W*H) 1160x560x565mm

Weight 116kg

Certification CE

After-sales Service Provided Overseas service center available

Specifications

Mini Lathe
1.Most popular, widely useful hobby lathe
2.Harden&precision ground bedway
3.Top design of quick change feed bore

Education or DIY mini lathe machine

Feature:

1. Variable speed

2. The spindle bore is 26mm

3. Safety magnetic switch or lock key switch

4. The spindle is supported with precision roller bearing

5. Precision ground and supersonice frequency hardened bed way

6. High accuracy and well wear-resisting

Specification:

Model	CQ6125V
Max. swing over bed	250mm
Max. swing over cross slide	150mm
Distance between centers	550mm
Width of bed	135mm
Spindle bore	26mm
Taper of spindle bore	M.T.4
Range of spindle speeds	125-2000rpm(variable)
Taper of tailstock quill	M.T.2
Metric threads can be cut	0.4-3.5mm
Inch threads can be cut	8-56TPI
Range of longitudinal feeds	0.07-0.2mm/rev
Max. travel of saddle	365/515/715mm
Max. travel of cross slide	110mm
Max. travel of top slide	70mm
Max. travel of tailstock quill	65mm
Motor power	750w
Packing size (L x W x H)	1155x 560 x 565mm
Net weight	116kg
