marine electrical wire 0.6/1kv

Specifications

marine electrical wire 0.6/1kv
1.tinned copper wire conductor
2.PVC PO insulation
3.ABS DNV LR GL CCS certificate

Marine electrical wire 0.6/1kv

Rating voltage: 600V/1000V

Construction:

1. Conductor: tinned copper wire,class2 or 5

2. Insulation: PVC/Polyolefin



marine electrical wire Specification

Cores: 1

Nominal Cross-section Areas:0.5mm2, 0.75mm2,1.0mm2, 1.5mm2, 2.5mm2, 4.0mm2, 6.0mm2, 10mm2,

16 mm2, 25mm2,  35mm2, 50mm2, 70mm2,95mm2

marine electrical wire Application

The cable is intended for power,lighting of shipboard or offshore building.

It is also available for power plant,chemical works and mines,etc.



marine electrical wire Classification Society Certificates

CCS,ABS,DNV,BV,LRS,GL,RINA,KR,NK.



The radius of bend for the installation of marine electrical wire

Cable structure features	Over diameter of cable(D)	Minimum internal bending radius
Metal braided armored	Any value	6D
Non-armored	D≤25	4D
	D25	6D
