433MHz adhesive antenna cavel

Name: 433MHz adhesive antenna cavel
Brand: Yetnorson
Price: USD $1 - 4.9 / Piece

FOB Price

USD $1 - $4.9 / Piece

500 Pieces(Min.Order)

Supply Ability 3 Piece / Pieces per Month
Port Shenzhen
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Guangdong, China

Brand Name:

Yetnorson

Model Number:

YNX-TQC-433-YJ35

Packaging Details

Standard Packing

Product Description

Specifications

433MHz adhesive antenna cavel
Long distance transmission
High gain;
Lower VSWR;
Signal stability;

433MHz adhesive antenna cavel

Electrical Specifications
Frequency Range (MHz)	433
Input Impendence (Ω)	50
V.S.W.R	≤1.5
Gain (dBi)	3.5
Polarization Type	Vertical
Radiation Direction	Omnidirectional
Max Input Power (w)	50
Mechanical Specifications
Antenna Length (mm)	280±3
Base Diameter(mm)	52*21
Cable (mm)	3000mm
Connect Type	SMA-Male
Mounting	3M Sticker
Radome Color	Black
Cable (mm)	RG174

Attachment	Welding
