Home > Manufacturing & Processing Machinery > Rubber Machinery > Rubber Product Making Machinery > High Quality China Supplier Dispersion Kneader X(S)N-75x30
High Quality China Supplier Dispersion Kneader X(S)N-75x30
US$ 20,000 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
Zhihong
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Best Price Gold Supplier Rubber Kneader Rubber Internal Mixer Rubber Dispersion Mixer Banbury Rubber Mixer MachineUS$ 20,000 - 80,000MOQ: 1 Set -
Made in China New Technology Banbury Rubber Mixer Machine Rubber Kneader Rubber Internal Mixer Rubber Dispersion MixerUS$ 20,000 - 80,000MOQ: 1 Set
-
Made In China Dispersion Rubber Mixer Machine 10L 20L 35L 55L 75LUS$ 20,000 - 80,000MOQ: 1 Set
-
20L 35L 55L China Manufacturer Banbury Rubber Mixer MachineUS$ 20,000 - 80,000MOQ: 1 Set
-
Bucket Elevator for SaleUS$ 4,000 - 80,000MOQ: 1 Set
Condition
New
Place of Origin
Shandong, China
Brand Name
Zhihong
Model Number
X(S)N-75x30
Voltage
220V-460V
Power(W)
110kw
Dimension(L*W*H)
3760x2143x3135mm
Weight
10200kg
Certification
ISO9001 CE SGS
Warranty
12 months
After-sales Service Provided
Engineers available to service machinery overseas
High Quality China Supplier Dispersion Kneader
Usage:
The rubber kneader is mainly used for plasticating and mixing rubber and plastics, and also applicable for mixing or kneading sticky materials.
Features:
- With completely sealed condition, materials are mixed or plasticated under certain pressure, controllable temperature, which makes high production efficiency and obtains excellent stable quality.
- Spiral angle and over lapping length of the blades of the rotors are of reasonable design and make the materials to be dispersed uniformly.
- Surface where is contacted with the materials are all plated with hard chromium and polished, which is corrosion-resistant and wear-resistant.
- Jacket construction is adopted in parts that surfaces contact with materials to achieve excellent water-cooling or steam heating effect and fit in with the needs of plastics and rubber precessing technology.
- Feeding from back door on the frame(or a separate top door)is convenient for continuous process operation in a production line. The mixing chamber is able to turn forward by 140°around the front rotors to discharge and is easy for changing pigments and cleaning the chamber.
- Programmable logic controller(PLC) is adopted in the electric-control system, which has reliable control function and alarm function, and interlock safety-protection function and it is procuded with serial interface of net.
Technical parameters:
model: X(S)N-75x30
Total kneading volume of mixing chamber :175L
Total mixing volume of mixing chamber:75L
Main moter power:110kw
Tilting moter power:2.2kw
Tilting angle:140°
rotate speed of rotor axis(front/back):30/24.5 r/min
pressure of compressing air:0.6-0.8Mpa
pressure of cooling water:0.2-0.4Mpa
pressure of heating vapour:0.5-0.8Mpa
overall size:3760x2143x3135mm(LxWxH)
weight:10200kg
