High Performance 16dBi Antenna GSM Panel Dipole Antenna External GSM Terminal Antenna
US$ 7.5 - 15
MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Yetnorson
Model Number:
YNX-GSM-HG-001-external gsm terminal antenna
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Manufactory ROHS GSM 3G Broadband Outdoor Antenna With N MaleUS$ 2.5 - 3.5MOQ: 50 Pieces -
External GSM Antenna, Outdoor/ Indoor GSM Antenna, 433mhz AntennaUS$ 1 - 3.5MOQ: 10 Pieces
-
Factory Supply New Appearance Wide Band Rubber Duck 3g 4g Lte Antenna With Sma ConnectorUS$ 0.8 - 1.02MOQ: 100 Pieces
-
GPRS GSM 3G UMTS SMA Antenna for USB ModemUS$ 0.8 - 2MOQ: 10 Pieces
-
Dual Band GSM/3G Antenna 2dbi SMA Plug Male for HuaWei Broadband RoutersUS$ 0.8 - 2MOQ: 10 Pieces
Place of Origin
Guangdong, China
Brand Name
Yetnorson
Model Number
YNX-GSM-HG-001-external gsm terminal antenna
Specifications
external gsm terminal antenna1) Frequency : 900/1800mhz
2) Connector : N female
3) Gain : 16dBi
4) ISO , ROHS , CE
High Performance 16dBi Antenna GSM Panel Dipole Antenna External GSM Terminal Antenna
| Electrical Specifications of external gsm terminal antenna | |
| Frequency Range (MHz) | 900/1800 MHz |
| Input Impendence (Ω) | 50 |
| V.S.W.R | ≤1.2 |
| Gain (dBi) | 16dBi |
| F/B Ratio | ≥15dB |
| Horizontal Beam width | 60°-90° |
| Vertical Beam width | 70°-70° |
| Polarization Type | Vertical |
| Power Capacity (w) | 100 |
| Mechanical Specifications of 2100mhz antenna | |
| Antenna Dimension | 210mm*180mm*45mm |
| Connector | N-Female |
| Weight | 0.6kg |
| Mounting Mast Diameter | Ø30~Ø50mm |
| Rated Wind Velocity | 210Km/h |
| Operating Temperature | -40°C to+80°C |
| Radome Material | UV protected ABS |
| Radome Colour | White |
| Mounting way | on the wall or hold in the pole |
Refund & Replacement
1. We can guarantee the product quality within one years .
2. If parts cannot work, we will return payment or replacement to you.
3. Any items must be returned in their original condition to qualify for a refund or replacement.
4. The buyer is responsible for all the shipping cost incurred.
Quality is essential to both of us, we believe that High quality, Low price,Mutual benefit will be good basis of our cooperation!!!
