Ball LED Display P6 LED Ball

Name: Ball LED Display P6 LED Ball
Brand: LINSO
SKU: 115231013
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

LINSO

Model Number:

Yeeso Multimedia Mobile Tech (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name LINSO

Model Number P6

Usage Indoor

Tube Chip Color Full Color

Display Function Video

Pixels Other, 6mm

Specifications

Ball LED Display P6 LED Ball is very attractive for advertising and promotion.

Ball LED Display P6 LED Ball

Technology Specifications
Name	Technology Specifications
1.Physical index	Pixel:6mm
	Color:Red+Green+Blue
	Pixel configuration:1R1G1B
	Pixel density:27778dots/sqm for the standard module
	LED type :SMD3528
2 Module	Panel pixel(dots):98000dots
2 Module	Modul size:irregular
3 Screen	Viewing:360⁰
	Storage temperature:-40°C_~~+65°C
	Operated temperature:-40°C~~+60°C
	Humidity:10%-95%
	Screen thickness:cabinet thickness 12cm(Front Maintenance)
	Protection:IP31
4 Power supply	Power: AC220Vor 380V
4 Power supply	Max power consumption:1200W/sqm average 500W/ sqm sqm
5 Control system	Computer:DELL V230 or similar computer
	Operating system:WIN7/2000/XP
	Display card:DVI
	Control mode:synchronization control
	Refresh frequency:≥2000Hz
	Grey/Color:16K,4K(Optional)/16.7M colors
	Calibrate Brightness:256level adjust
	Control system adopts:DVI+Master card+ Internet line
6 Main specifications	Driver:Constant current
	Driver mode:1/8 scan
	Frame frequency:≥60Hz
	Brightness:≥2000cd/sqm
	Accepting signal:RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION etc
	MTBF:≥1000hours;Life-span:100,000hours
	Level up degree:pixel≤0.5mm;module<1mm
	Uniformity:pixel and module uniformity brightness
	Malfunction dot rate:<0.0001
	Switch power load:5V/40A
	Computer display mode:1024×768
	Control distance:internet line :100m;single mode fiber: 20km;multi mode fiber:500m
