Product Details
Place of Origin: | Henan, China | Brand Name: | Pengda | Model Number: | JM |
Power Source: | Other, Electric, 380V 50Hz 3phase or according to your demand | Application: | Other, boat, mine, crane, chimney and equipment installation, etc | Capacity: | 10~650KN |
Product Description
Electric anchor winches for boats
Introduction
JM series electric winch is gears reducer driving .Mainly used for hoisting pull drag the weight drop.Be widely used in boat, port, workshop, warehouse, construction and many kinds producing-line, so is necessary equipment for lifting goods, raising labor efficiency, improving working conditions.
Ø The capacity: 1t, 1.6t, 2t, 3.2t, 5t, 6t, 8t, 10t, 12.5t, 13.5t, 16t, 20t, 25t, 32t, 50t, 65t
Ø The rated load: 10, 16, 20, 32, 50, 60, 80, 100, 125, 135, 160, 200, 250, 320, 500, 650KN
Ø Working grade: M5
Ø Lifting unit: Wire rope
Ø Rated speed: 0~20m/min or as your demand
Ø Working temperature: -25~+40 centigrade
Electric winch pictures show
Main technical specification
Model
| Rated load (KN) | Rated speed (m/min) | Rope length (m) | Rope diameter (mm) | Motor type | Motor power (KW) | Overall dimension (mm) | Weight (kg) |
JM1 | 10 | 15 | 100 | 9.3 | Y112M-6 | 3 | 620*701*417 | 270 |
JM1.6 | 16 | 16 | 150 | 12.5 | Y132M-6 | 5.5 | 945*996*570 | 500 |
JM2 | 20 | 16 | 150 | 13 | Y160M-6 | 7.5 | 945*996*570 | 550 |
JM3.2 | 32 | 9.5 | 150 | 15.5 | YZR160M-6 | 7.5 | 1430*1160*910 | 1100 |
JM5 | 50 | 10 | 270 | 21.5 | YZR160L-6 | 11 | 1235*1230*805 | 1560 |
JM6 | 60 | 9.5 | 270 | 24 | YZR180L-6 | 15 | 1235*1509*805 | 1800 |
JM8 | 80 | 8 | 250 | 26 | YZR180L-6 | 15 | 2090*1475*956 | 2900 |
JM10 | 100 | 8 | 170 | 30 | YZR200L-6 | 22 | 2090*1475*956 | 3000 |
JM12.5 | 125 | 8 | 300 | 34 | YZR225M-6 | 30 | 2880*2200*1550 | 5000 |
JM13.5 | 135 | 8 | 290 | 28 | YZR225S-8 | 22 | 2990*2363*1650 | 6500 |
JM16 | 160 | 10 | 500 | 37 | YZR250M2-8 | 37 | 3750*2400*1850 | 8800 |
JM20 | 200 | 10 | 600 | 43 | YZR280S-6 | 45 | 3950*2560*1950 | 9900 |
JM25 | 250 | 9 | 700 | 48 | YZR280M-8 | 55 | 4350*2800*2030 | 13500 |
JM32 | 320 | 9 | 700 | 56 | YZR315S-8 | 75 | 4500*2850*2100 | 14800 |
JM50 | 500 | 9 | 800 | 65 | YZR315M-8 | 90 | 4930*3050*2250 | 19500 |
JM65 | 650 | 10 | 800 | 64 | LA8315-8AB | 160 | 5900*4680*3200 | 46000 |
Sketch of winch
Breakdown pictures of electric winch
Delivery pictures
Customers Visiting
CE certificate
Service
1) Pre-sale service:
Freely provide project designing, process designing, choosing suitable equipment for you.
2) Medium-sales service:
Accompany you to complete the acceptance of the equipment,draft the construction scheme and detailed process, and complete process of export.
3) After-sales service:
u 14 months warranty from the date of B/L
u One year quick-wear parts for free
u Professional technicians provide installation, commissioning services
u Technical advisory for any time
FAQ
If you are interested in our winch, Please confirm the below information:
1. Capacity of winch
2. Length of wire rope
3. Industrail voltage
4. What the winch will be used to do?
Welcome contact us by email or chat online, our professional engineers and technicians will serve you with all technical support, and we will offer you best service.
