Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > CK6130 Flat Bed Boxway CNC Lathe CK6125

CK6130 Flat Bed Boxway CNC Lathe CK6125

Name: CK6130 Flat Bed Boxway CNC Lathe CK6125
Brand: Pulute Machine PULUTEK
SKU: 115202543

CK6130 Flat Bed Boxway CNC Lathe CK6125 thumbnail-1

CK6130 Flat Bed Boxway CNC Lathe CK6125 thumbnail-2

CK6130 Flat Bed Boxway CNC Lathe CK6125 thumbnail-3

CK6130 Flat Bed Boxway CNC Lathe CK6125 photo-1

CK6130 Flat Bed Boxway CNC Lathe CK6125 photo-2

CK6130 Flat Bed Boxway CNC Lathe CK6125 photo-3

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Contact Supplier Request Quote Chat Now

Shandong Pulute Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Shangai Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Horizontal

CNC or Not CNC

Automatic Grade Automatic

Max. Swing Diameter 300mm 250mm

Place of Origin Shandong, China

Brand Name Pulute Machine PULUTEK

Model Number CK6130 CK6125

Voltage 200/400V

Power(W) 5.5kw

Dimension(L*W*H) 2000*1200*1620mm

Weight 1800KG

Certification ISO CE

After-sales Service Provided Engineers available to service machinery overseas

Product Description

CK6130 CK6125

Flat bed BOXWAY CNC LATHE

Pipe threading Lathes, auto-lathes

1. SPECIFICATION

	CK6130
Max. swing over bed	Φ300 mm
Max. swing over cross slide	Φ90 mm
Max. cutting length	With chuck:: 290 mm / with collet:: 400 mm
Spindle bore	Φ48 mm
Max. diameter of the bar	Φ41 mm
Spindle nose	A2-5
Spindle speed	150-2500 rpm
Spindle motor power	4 kw
X/Z axis travel	300/380 mm
X/Z axis torque	4/4 kw
X/Z axis rapid feeding speed	8/10 m/min
X/Z axis position accuracy	0.01/0.015 mm
X/Z axis repeatability	0.012/0.013 mm
Tool bar section	16*16 mm
Tailstock sleeve dia.	Φ52 mm
Tailstock sleeve travel	100 mm
Tailstock taper	MT4#
N.W.	1200 kg
Machine dimension (LWH)	175012001570 mm

2. FEATURES

Frequency stepless speed

With servo system

4-station electric turret

3. USAGE

This machine is widely used in processing the electrical appliance, instrumentation, automobile, motorcycle, fastener, bearing, photographic and film machinery, hardware tools, watches, glasses, stationery motors, valves, gas pipe and other high precise and complex components. It is the ideal high efficient equipment in hardware machinery industry.

4. STANDARD ACCESSORIES

China GSK980TDC, KND or Siemens 808d CNC system

Frequency inverter motor 4kw

spring collet

5. OPTIONAL ACCESSORIES

KND100Ti or Fanuc 0I mate-TD

servo motor 3.7/5.5 kw

inverter motor 5.5 kw

160mm manual chuck

160mm thru-hole hydraulic chuck

160mm none thru-hole hydraulic chuck

160mm thru-hole hydraulic chuck (Taiwan brand)
