Specifications
1. high capacity2. Low running cost
3. Easy maintenane
YZ series round vibrating screen has 4 blankets of eccentric combination, the universal joint coupling makes it synchronous operation to reach the best vibrating result. The tyre shaft coupling passes the motor's rotation to the axion's axle, under the function of the eccentric block, the axion axle does unequal centrifugal force rotation, the major machine realizes the full vibration under the support of spring to size the material.
Performance features:
1. The mortor adopts tyre shaft coupling, preventing the motor being damaged for twisting when it starts.
2. Adopt rubber spring, the whole machine's operation is stable and reliable, the operating life is long.
3. Adopt combined exciter and cardon movement, to assure the operation simultaneous, and exclude the phenomenon of bearing effecting the operating life as its coaxial degree is not very good.
4. Adopt aircooling craft,reducing the bearing temperature, prolonging the bearing's operating life.
5. Adopt high-strength bolts combinate craft, making the sieve body's operating life more durable under the full vibration.
Applicability:
Widely applied to the sievinging of building materials, metallurgy, chemical industry, roads and bridges, mine etc materials.
Specifications:
Model |
Number of Layers of Screen |
Dip of Groove Surface (°) |
Capacity (t/h) |
Motor power (KW) |
YK-1548 |
1 |
20 |
50-200 |
11 |
2YK-1548 |
2 |
20 |
50-200 |
11 |
3YK-1548 |
3 |
20 |
50-200 |
15 |
4YK-1548 |
4 |
20 |
50-200 |
18.5 |
YK-1860 |
1 |
20 |
80-280 |
18.5 |
2YK-1860 |
2 |
20 |
80-280 |
18.5 |
3YK-1860 |
3 |
20 |
80-280 |
22 |
4YK-1860 |
4 |
20 |
80-280 |
22 |
2YK-2160 |
2 |
20 |
100-450 |
22 |
3YK-2160 |
3 |
20 |
100-450 |
30 |
4YK-2160 |
4 |
20 |
100-450 |
30 |
Pre-sales
1.Customers can open Chengming company website for inquiring the relevant information.
2.Customers can go to the Chengming sales department for knowing detail information by telphone, e-mail, fax or other methods.
3.Chengming company arranges full time customer manager for customers, offering detail introduction and engineering technology solutions.
4.Can arrange customers nearby investigation of Chengming products service condition.
5.Chengming company customer service engineers go to customer work-site for assisting in the design and provide a feasibility plan.
Sale-in
1.Can directly go to the customer work-site or Chengming company for investigation, negotiation and signing a contract.
2.Providing. foundation drawings of the equipment and on-site guidance, timely answer customer technical problems encounterde in the construction.
3.According to the contract requirements of the quality, quantity, delivery on time.
4.Can consigning shipment for customers.
5.Customer service engineers can go to the work-site to guide the installation, commissioning, training operators, to achieve customer satisfaction.
After-sale
1.Paying a return visit regularly, to know the equipment service condition.
2.In the warranty period, receives the customer breakdown telephone, within 2 hours to provide solution, if need the expatriates, within 48 hours to arrive at the work-site, to assist in troubleshooting until return to normal production.
3.Ensure timely supply of high quality spare parts.
4.For the customers whom use Chengming products, we will give life-long technical
Our honors:
