Mining Double Roller Crusher in India

Specifications

1 Reliable, stable operation.
2 Simple repair, long service life.
3 Low running costs, save resources
4 Hot selling in Africa

Introduction:

Hydraulic roll crusher has the advantages of simple structure, small occupation, convenient to repair and operate. Interior is equipped with dust-proof plate, good sealing performance, avoid splashing fine material after crushing. And the little dust with low noise make the work environment improved. Our roller body has optimized design which makes the roller can be used for life without changing the roller,but the old roller machine which has been used for a year would need to be opened for repairing and replacing the roller. This machine is widely used in cement production line, sand making production, building materials, mining, chemical, steel, cement and other industries which need fine materials.



Working principle:

Through the feed opening, the raw materials fall to between the two rollers, after crushed, the final products drop naturally. When there are unbreakable materials or the material is too hard, the roller will concede automatically under the effects of spring and hydraulic pressure, which will widen the clearance between the rollers and make the hard or unbreakable so as to avoid damaging the machine. The clearance between the two rollers can be adjusted to change the sizes of final products.



Main technical parameter:

Model	Roll Diameter(mm)	Capacity(t/h)	Feed Size(mm)	Output Size(mm)	Reducer	Motor
600×400	600	12	< 20	< 3 about 75%	ZLY180-20-I×2	Y180L-6 15KW×2
800×600	800	25	< 25	< 3 about 72%	ZLY280-20-I×2	Y200L2-6 22KW×2
1000×700	1000	40	< 30	< 3 about 70%	ZLY224-20-I×2	Y225M-6 30KW×2
1200×700	1200	70	< 40	< 5 about 70%	ZLY280-20-I	Y280M-6 55KW×2
					ZLY280-20-IV
1200×800	1200	70	< 40	< 3 about 65%	ZLY280-20-I	Y280M-6 55KW×2
					ZLY280-20-IV
1500×700	1500	150	< 50	< 5 about 72%	ZLY335-20-I	Y315L2-8 110KW×2
					ZLY335-20-IV
1500×800	1500	150	< 50	< 3 about 70%	ZLY335-20-I	Y315L2-8 110KW×2
					ZLY335-20-IV
1800×800	1800	210	< 60	< 3 about 75%	ZLY450-20-I	Y355M2-8 160KW×2
					ZLY450-20-IV
2000×1000	2000	350	< 70	< 5 about 72%	ZLY560-31.5-I	Y355L1-6 220KW×2
					ZLY560-31.5-IV



We are providing you with comprehensive and practicable crushing and screening program.



Our services:

Pre-sales

1.Customers can open Chengming company website for inquiring the relevant information.

2.Customers can go to the Chengming sales department for knowing detail information by telphone, e-mail, fax or other methods.

3.Chengming company arranges full time customer manager for customers, offering detail introduction and engineering technology solutions.

4.Can arrange customers nearby investigation of Chengming products service condition.

5.Chengming company customer service engineers go to customer work-site for assisting in the design and provide a feasibility plan.

Sale-in

1.Can directly go to the customer work-site or Chengming company for investigation, negotiation and signing a contract.

2.Providing foundation drawings of the equipment and on-site guidance, timely answer customer technical problems encounterde in the construction.

3.According to the contract requirements of the quality, quantity, delivery on time.

4.Can consigning shipment for customers.

5.Customer service engineers can go to the work-site to guide the installation, commissioning, training operators, to achieve customer satisfaction.

After-sale

1.Paying a return visit regularly, to know the equipment service condition.

2.In the warranty period, receives the customer breakdown telephone, within 2 hours to provide solution, if need the expatriates, within 48 hours to arrive at the work-site, to assist in troubleshooting until return to normal production.

3.Ensure timely supply of high quality spare parts.

4.For the customers whom use Chengming products, we will give life-long technical service.
