| china best cnc lathe |
CK7156/20/30 CNC lathes are the latest products manufactured with advanced thchnologies licensed by Daewoo Heavy Industries Ltd. (South Korea). Its strength, dynamic and static rigidity, mechanics of main parts, safety device and cooling system are all designed according to Turning Center. The strengthed casting base and exclusive slant bed provide excellent rigidity and dampening, coupled with convenient chip removal. A high precision through-hole spindle driven by powerful AC main motor feature the stability and low noise during operation. Key parts like bearing on the ball screw and main spindle are all famous foreign products, ensuring the higher machining accuracy and longer part life. The multi-station turret indexed fast and nonstop bi-directionally with a high repeatability.
The CNC system is optional with FANUC0-TC, 0-TDII or others as required. The hydraulic parts, lubrication unit and chuck are all famous domestic or foreign products as well.
The new designed CK7516/20/25/30 feature easy panel operation and complete protection. They are undoubtedly the most powerful products in their class due to their excellent accuracy and stability.
Feature:
1.Powerful AC Spindle Motor
2.Massive Low End Spindle Torque
3.Larger Spindle Bore
4.Oversize Ball Screw and AC Servo Motor
5.Rigid Slant Bed
6.Hardened and Ground Guideways
7.Non-stop Bi-directional Electric Turret
8.Programmable Tailstock Body and Quill
9.Asial Protective Torque Limiter Clutch
10.Automatic Tool Setter
11.Fast Rapid Traverse
12.32-Bit CNC System
13.Air Exchange and Moisture Proof
14.Elctricity
15.Unit Dial Indicationg Hydraulic Pressure
16.Regulator
| china best cnc lathe |
| china best cnc lathe |
| ITEM | UNIT | LFNC7516 | LFNC7520 | LFNC7525 | LFNC7530 | |
| Capacity | Swing diameter over bed | mm | Φ400 | Φ550 | Φ550 | Φ670 |
| Max. turning diameter | mm | Φ285 | Φ450 | Φ450 | Φ500 | |
| Max. turning length | mm | 400 | 530 | 1000/1500 | 800/1500 | |
| Max. bar diameter | mm | Φ42 | Φ73 | Φ73 | Φ90 | |
| Spindle | Type of spindle nose | A2-5 | A2-8 | A2-8 | A2-8 | |
| Spindle bore diameter | mm | Φ57 | Φ87 | Φ87 | Φ105 | |
| Chuck diameter | mm | Φ165 | Φ254 | Φ254 | Φ305 | |
| Spindle speed | rpm | 55-5500 | 30-3000 | 30-3000 | 25-2500 | |
| Spindle motor power (Continuous/30min) | Kw | 11/15 | 15/18.5 (*18.5/22) | 15/18.5 (*18.5/22) | 22/30 | |
| Tailstock | Quill diameter | mm | Φ70 | Φ9 | Φ90 | Φ110 |
| Quill travel | mm | 80 | 100 | 100 | 150 | |
| Taper of center (Standard/live spindle) | MT | 4/2 | 5/4 | 5/4 | 6/5 | |
| Feed | Travel X/Z | mm | 165/410 | 250/1010 | 250/1010 | 295/1550 |
| Rapid traverse rate X/Z | m/min | 12/16 | 16/20 (*12/15) | 16/20 (*12/15) | 12/16 | |
| Feed motor torque X/Z | N.m | 6/12 | 12/22 | 12/22 | 12/22 | |
| Turret | Number of turret | 12/8 | 12/8 | 12/8 | 8 | |
| Tool O.D. size (turning/boring) | mm | 20 x 20/Φ32 | 25 x 25/Φ40 | 25 x 25/Φ40 | 32 x 32/Φ50 | |
| Other | Slant degree of bed | 45 | 45 | 45 | 60 | |
| Power supply | KVA | 35 | 35 | 50 | 60 | |
| Dimension (L x W x h) | mm | 2535 x 1672 x 1662 | 3255 x 1805 x 1850 | 3655 x 1990 x 1880 | 4822 x 2244 x 2178 | |
| Weight | kg | 3000 | 4500 | 5000 | 8300 | |
| Old model | CK7516 | CK7520 | CK7525 | CK7530 | ||
Welcome to Almaco Machine Tool Co., Ltd
our company as the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation,specializes in import & export of brand-new industrial machinery & tools.Our mechanical products with ISO9001 or CE certificate cover more than 80 kinds including lathe ,milling machine,grinding machine,power press,guillotine shearer,hydraulic press brake,CNC Machine and so on,which have been exported to 40 or more countries & areas.
The machines are packed with wooden case or depend on your requires.
Regarding to the shipping, the machine will be deliveried to your destination ports or place you assign
Our engineer team
*******************************************************************************************************
1.All of our goods will pass QUALITY INSPECTIONS before shipment.Best after sale service, customer can follow their order situation any time, no matter on product line, warehouse or shipment.
2.More than 5 years experience in exporting to make your order more smooth.Less than one container loading is accepted.
On time delivery, in general 30 days. Multimode payment:T/T,L/C.
3.Special dimensions available according to request.
4.We have many certificates of our Products.
5.Accessories replacement if our product itself has quality problems during one year after receiving.
