100KHz-150MHz High Frequency Signal Generator

100KHz-150MHz High Frequency Signal Generator thumbnail-1
100KHz-150MHz High Frequency Signal Generator photo-1
Negotiable MOQ: 2 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
LW
Model Number:
TSG-17
Contact Supplier Request Quote Chat Now
Dongguan Longwei Electronic Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
yantian shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name LW
Model Number TSG-17

Specifications

Complete technologies of Japanese electrical equipment
assembly with imported components

Features

     Complete technologies of Japanese electrical equipment and assembly with imported components ensure minimum accuracy deviation.

     Signal frequency: 100 kHz to 150MHz, 3 harmonic up to 450MHz.

     Output wave form: sine and amplitude modulation wave.

     RF/AM output, max, intensity≥10VP-P.

     External modulation signal can be set between 50Hz to 20 KHz.

Specifications:

     Frequency ranges: A: 100 KHz to 300 KHz   B: 300 KHz to 1MHz

                                 C: 1MHz to 3.2MHz     D: 3MHz to 10MHz

                                 E: 10MHz to 35MHz    F: 32MHz to 150MHz

     Frequency range: 100 KHz to 150MHz (3 harmonic wave up to 450MHz)

     Frequency accuracy: Over±5%

     Output waveform: RF/AM signal waveform

     Output impedance: 600Ω

     Radio frequency output: Over 100Mv rms (when frequency ≤35MHz)

     Level control: 1mV to100mV

     External modulation: 150Hz to 1.5 KHz.  Amplitude from 0 to 30% adjustable.

     Normal operation: 50Hz to 20 KHz for any setting.

     Temperature/Humidity: 10 oC to 35 oC/with 85%RH

     Power supply: 220V/110V+/-10%, 50Hz/60Hz

     Dimensions: 239*140*200mm

     Weight: 2.5kg
