HK LONGWEI INSTRUMENTS Portable AC DC Voltage LCD Display Digital Multimeter
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
LONGWEI
Model Number:
LW830L
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LCD Handheld Electrical Tester Digital Clamp Multimeter AC Clamp MeterNegotiableMOQ: 1 Piece -
True RMS Clamp Meter Complete ac dc Clamp Meter With Pocket SizeNegotiableMOQ: 1 Piece
-
HK LONGWEI INSTRUMENTS Portable Clamp Meter Series AC Current Clamp Meter DC Clamp MeterNegotiableMOQ: 1 Piece
-
HK LONGWEI INSTRUMENTS Intelligent Digital Multimeters Digital Handhelp MultimeterNegotiableMOQ: 1 Piece
-
hk Longwei Instruments Portable Digital Multimeter With Good Price Sale From ManufacturerNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
LONGWEI
Model Number
LW830L
Measuring Current Range
200μA/2mA/20mA/200mA/10A
Measuring Voltage Range
200mV/2V/20V/200V/600V
Measuring Resistance Range
200Ω/2KΩ/20KΩ/200KΩ/2MΩ
Operating Temperature
18℃ to 28℃(64℉to 82℉)
Dimensions
138*69*31mm
Multimeter LW830L
Feature | ||
Display | 3 1/2digits 1999counts | |
hFE | 1 ~ 1000 | |
Data hold | Yes | |
Diode test | Yes | |
Continuity | Yes | |
Background light | Yes | |
Specification | ||
Function | Range | Accuracy |
Voltage DC | 200mV/2V | ±(0.5%+3) |
20V/200V/600V | ±(0.8%+2) | |
Voltage AC | 200V/600V | ±(1.2%+10) |
Current DC | 200μA/2mA/20mA | ±(1%+2) |
200mA | ±(1.5%+2) | |
10A | ±(3%+10) | |
Resistance | 200Ω/2KΩ/20KΩ/200KΩ | ±(0.8%+2) |
2MΩ | ±(1%+2) | |
hFE | 1 ~ 1000 | N.A |
Environmental | ||
Normal Operation | 18℃ to 28℃(64℉to 82℉) | |
Usable Condition | 0℃ to 50℃(32℉to 122℉) | |
Storage Temperature | -20℃ to 60℃(30℉to 140℉) Battery removed and <80%R.H. | |
Relative Humidity | MAX.80% | |
General | ||
Size | 138*69*31mm | |
Weight | 170g (battery included) | |
Battery | 9V NEDA 1604/6F22 | |
Packing &Delivery Details
Packaging details:Gift box for Multimeter Ohms
Delivery Detail:Depend on QTY for Multimeter Ohms
