ALMACO waterjet cutting machine
- 32 Set / Sets per Month
- Shanghai Port
- T/T L/C D/P D/A Credit Card PayPal
- Band Saw Blades
- Band Saw Machine
- G800 6-axis CNC Gear Hobbing Machine CNC Machine Gear Cutting Gear Cutting CNC Machine
- New G800 CNC Gear Hub Machine with Automation Loading/unloading Solution 8-10M Hobbing Machine
- China YQ31250E gear hobbing machine OME
- Y31160 gear hobbing machine for sale from dalian zhuanghe
Product Details
Condition: | New | Type: | Other, cutting machine | CNC or Not: | CNC |
Place of Origin: | China | Brand Name: | SYMEX | Model Number: | CR420 |
Voltage: | 380V or as your requirement | Power(W): | w | Dimension(L*W*H): | mm |
Weight: | kg | Certification: | CE&ISO9001 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
| Creative316 | Creative 420 |
X Axis Cutting Stroke | 3m | 4m |
Y Axis Cutting Stroke | 1.6m | 2m |
Z axis Stroke | 180mm | 180mm |
CNC Control | SEMYX | SEMYX |
CAM Software | Included | Included |
Cutting Speed | 0-15m/min | 0-15m/min |
Free Speed | 20m/min | 20m/min |
Acceleration | 1m/s2 | 1m/s2 |
Accuracy | 0.05mm(0.002") | 0.05mm(0.002") |
Drivers | AC Servo Motors | AC Servo Motors |
Motion for X Axis | Ball Screw | Ball Screw |
Motion for Y Axis | Ball Screw | Ball Screw |
Motion Part Protection | Double Protection | Double Protection |
Pump | 50hp | 50hp |
Z -axis | 1 | 1 |
Water Treatment System | optional | optional |
Abrasive Tank Capacity | 350 L | 350 L |
Abrasive Feeder | Automatic | Automatic |
Abrasive Removal | optional | optional |
Dual Z-Axis | none | optional |
Dual Cutting Head | optional | optional |
Body | stainless steel | stainless steel |
Footprint Length | 2.27m | 2.65m |
Footprint Width | 4.02m | 5.17m |
Maximum Height | 1.75m | 1.75m |
