ALMACO high efficiency water jet high pressure cutting machine
- 35 Set / Sets per Month
- Shanghai Port
- T/T L/C D/P D/A Credit Card PayPal
- Hydraulic Guillotine Type Metal Shear Used in Scrap Metal Recycling Industry
- Best price cnc table plasma cutting machine with water table
- High-power cnc plasma cutting machine 1530
- REBOUND CNC table plasma cutting machine for metal 1.5x3m
- REBOUND CNC new automatic plasma cutting machine with good price
- table cnc best price modern plasma cutting machine for stainless
Product Details
Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | ALMACO |
Model Number: | Creative 420 | Voltage: | 380V or as your requirement | Rated Power: | 50-100hp |
Dimension(L*W*H): | 2.65*5.17*1.75m | Weight: | up to your choice | Certification: | CE&ISO9001 |
Warranty: | 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
water jet high pressure
water jet high pressure
1.Dual X-axis:Ensure the highest level of rigidity for precision and accuravy. For customers who are looking for that extra intricate cutting, the Creative is best solution
2.Fully sealed ball screw: Sealed X-axis guides and ball screws eliminate the risk of abrasive abrasion of the precision surfaces. We have ensured that no moisture is trapped or collected which may affect sensitive mechanical parts
3.Fully enclosed cable channels: a unique feature in waterjet machines gives you extra pretection from dirt and water extending the life of your machine
4.Body: The only machine in the market with full stainless steel body. Motion control, cutting table and all electrical hardware are in the main block of the machine. Seperate pump and abrasive tank.
water jet high pressure
Item | Specification | ||||||
Creative 316 | Creative 420 | ||||||
X Axis Cutting Stroke | 3m (120") | 4m (156") | |||||
Y Axis Cutting Stroke | 1.6m (63") | 2m (78") | |||||
Z Axis Stroke | 18cm (7 in . ) | 18cm (7 in .) | |||||
Control | CNC | CNC | |||||
CAM Software | included | included | |||||
Cutting Speed | 0-15m/min (0-200"/min) | 0-15m/min (0-201"/min) | |||||
Free Speed | 20m/min (800"/min) | 20m/min (801"/min) | |||||
Acceleration | 1m/s² | 1m/s² | |||||
Accuracy | 0.05mm(0.002") | 0.05mm(0.002") | |||||
Drivers | AC Servo Motors | AC Servo Motors | |||||
Motion for X Axis | Ball Screw | Ball Screw | |||||
Motion for Y Axis | Ball Screw | Ball Screw | |||||
Motion Part Protection | Double Protection | Double Protection | |||||
Recommended Pump | 50-60hp | 50-100hp | |||||
Cutting Heads | 1 | 1—2 | |||||
Multiple Gantry | no | no | |||||
Z axis | 1 | 1—2 | |||||
Anti-Height | optional | optional | |||||
Water Treatment System | optional | optional | |||||
Water Level Control | optional | optional | |||||
Automatic Tilting Head Mechanism | optional | optional | |||||
Abrasive Tank Capacity | 350 L | 350L | |||||
Abasive Feeder | Automatic | Automatic | |||||
Abrasive Removal | optional | optional | |||||
Camera Vision System | optional | optional | |||||
Dual Z-Axis | no | optional | |||||
Dual Cutting Head | optional | optional | |||||
Body | stainless steel | stainless steel | |||||
Footprint Length | 2.27m (89") | 2.65m (105") | |||||
Foorprint Width | 4.02m (158") | 5.17m (204") | |||||
Footprint Height | 1.75m (144") | 1.75M (156") |
water jet high pressure
The machines are packed with wooden case or depend on your requires.
Regarding to the shipping, the machine will be deliveried to your destination ports or place you assign
Experienced Engineer Team Especially for the
water jet high pressure
******************************************************
1.All of our goods will pass QUALITY INSPECTIONS before shipment.Best after sale service, customer can follow their order situation any time, no matter on product line, warehouse or shipment.
2.More than 5 years experience in exporting to make your order more smooth.Less than one container loading is accepted.
On time delivery, in general 30 days. Multimode payment:T/T,L/C.
3.Special dimensions available according to request.
4.We have many certificates of our Products.
5.Accessories replacement if our product itself has quality problems during one year after receiving.
water jet high pressure
Our products are exported to more than 50 countries, more than 700 customers
