Home > Industrial Equipment & Components > Power & Generating Sets > Wind Generator > Small Hydropower Turbine

Small Hydropower Turbine

Name: Small Hydropower Turbine
Brand: HNAC
SKU: 115109575
Availability: InStock

US$ 1 - 600 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Hunan, China

Brand Name:

HNAC

Model Number:

50-20000KW

Contact Supplier Request Quote Chat Now

HNAC Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Chinese Sea Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hunan, China

Brand Name HNAC

Model Number 50-20000KW

Type Generator

Electricity Generator Type Hydro Power

small hydropower turbine

Water Turbine/Hydro turbine /Tubula

Product Description

No.	Name	Description	Type	Features
1	Francis Turbine	Francis Turbine is widely used in hydropower plants with low, middle and high water head commonly ranging from 30m to 300m, The maximum water head can be 500m, The unit has advantages such as: compact structure and high efficiency.	Horizontal type	Its feature is that the water flow enters the runner inward in a radial direction, changes direction gradually and then passes out axially. Francis turbine is characterized by reliable operation, simple construction and hight efficiency, etc.
			Vertical type
2	Axial Flow Turbine	Axial Flow Turbine is used in hydropower plants with low and middle water head commonly ranging from 3m to 30m. It can be divided into Propeller /Fix Blade Type (ZD) and Kaplan/ Movable Blade Type (ZZ), Propeller turbine is used in the power plant whose flow varies little. Kaplan turbine is used in the power plant with the flow varying much; its adjustable blades can change the angle automatically so that it can guarantee high efficient operation under different flow and load.	Propeller/ Fix blade type(ZD)
			Kaplan/ Movable blade type(ZZ)
3	Pelton Turbine	Pelton Turbine is used in hydropower plants with middle and high water head, generally ranging from 90 m to 600 m, the maximum water head can reach 1200 m. It can be divided into single nozzle type and multiple nozzle type.	Single nozzle type
			Multiple nozzle type
4	Turgo Turbine	Turgo turbine has its unique application range, is commonly used in the hydropower plants with water head ranging from 25 m to 190 m, Francis and Pelton type are not suitable.
5	Pit Type Tubular Turbine	Pit type tubular turbine is a new hi-tech product. It is well suitable for hydropower plants with water head ranging from 2 m to 10 m and unit capacity below 15MW. It has the following particular advantages: Its efficiency is higher than shaft-extension type tubular units and axial flow units; its cost is lower than axial flow units and bulb tubular units, and it is convenient to operate and maintain. Pit type tubular turbine is divided into fixed blade type (GD) and moveable blade type (GZ).	Fixed blade type (GD)
			Moveable blade type (GZ)

Specification:

Water turbine/Hydro turbine

1. Single unit capacity: 50kW-30000kW
2. Multi types: Kaplan/Axial/flow turbine, Propeller turbine, Francis turbine, Pelton turbine Tubular turbine and Turgo turbine
3. Envionment friendly
4. Long life: 30-50 years

Kinder reminder:

If you are interested in the Turgo turbine, you should send some key parameters (such as net head, flow discharge, unit number, frequency, voltage) in inquiry.

1.The most suitable choice

HNAC makes the most appropriate choice of renewable energy source and the system to be used.

2.The most profitable investment
HNAC offers you the most suitable and profitable energy investment by analysing your energy needs.

3. Efficient High Level Technology
HNAC supplies and installs the most efficient equipment for energy production with the latest technology.

4. Service and Spare parts
HNAC provides the highest quality spare parts and after sales services for system continuation and maintenance after installation.

5. Qualify Assurance

The company fully carry out ISO9001:2008 management system, all the procedures are strictly monitored under the relevant quality control statement, including equipments’ design, producing, testing, packaging, transportation and after-sale service.
