Home > Metallurgy, Mineral & Energy > Steel & Products > Steel Pipe & Tube > Welded Large Diameter Carbon Steel Tube

Welded Large Diameter Carbon Steel Tube

Welded Large Diameter Carbon Steel Tube thumbnail-3

Welded Large Diameter Carbon Steel Tube thumbnail-4

Welded Large Diameter Carbon Steel Tube thumbnail-5

Welded Large Diameter Carbon Steel Tube thumbnail-6

Welded Large Diameter Carbon Steel Tube photo-1

Welded Large Diameter Carbon Steel Tube photo-2

Welded Large Diameter Carbon Steel Tube photo-3

Welded Large Diameter Carbon Steel Tube photo-4

Welded Large Diameter Carbon Steel Tube photo-5

Welded Large Diameter Carbon Steel Tube photo-6

US$ 400 - 1,500 MOQ: 50 Tons

Key Specifications

Get Latest Price

Standard:

Grade:

Thickness:

6, 26

Contact Supplier Request Quote Chat Now

Weifang East Steel Pipe Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO CHINA

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Thickness 6, 26

Section Shape Round

Outer Diameter 219 - 2200 mm

Place of Origin Shandong, China

Secondary Or Not Non-secondary

Application Other, Boiler,Chemical Fertilizer,Structure,Fluid,Gas,Hydralic,Oil Pipes

Technique SAW

Certification Other, ISO CE API UL

Surface Treatment Other, Black,PE/PP,Expoder Coated,Painted,Galvannized

Special Pipe API Pipe

Alloy Or Not Non-alloy

Our company WEIFANG East Steel Pipe Co.,Ltd. has the most advanced double-sided submerged arc welding steel tube production lines and can produce the SSAW pipes with diameter θ219mm-θ2200mm and wall thickness from 6mm to 30mm. The double-sided submerged arc welding processing boasts not only with high deposition rate, but also with deep penetration ability, good quality and appearance of welding line and high density. All these can meet the requirements of welding line.

Spiral steel pipe was made by steel coil, extrusion forming under the normal temperature, and was taken the technology of double wire and double-faced submerged-arc welded.

Technological Characteristics:

During the molding process of the spiral welded steel pipe, the steel plate has uniform deformation and light residual stress, and the surface has no scratches. The pipe made by the spiral pipe manufacturer has more flexible thicknesses and diameters. Especially in making high-grade thick pipes with small or medium aperture, this kind of techniques has incomparable advantages that can satisfy more requirements on spiral welded pipes.

Application:

Spiral steel tube was mainly used in public waterworks, petrochemical industry, chemical industry, electric power industry, agricultural irrigation and urban construction etc.

For liquid transportation: water supply, drain off water, petroleum transportation, etc.

For gas transmission: coal gas, steam, liquefied petroleum gas, gas etc.

For structure: piling, bridge, wharf, road, architectural structure, etc.

Material:

Q235A, Q235B, 10#, 20#, Q345(16Mn), L245(B), L290(X42), L320(X46), L360(X52), L390X56), L415(X60), L450(X65), L485(X70), L555(X80), L290NB/MB(X42N/M), L360NB/MB(X52N/M), L390NB/MB(X56N/M), 415NB/MB(X60N/M), L450MB(X65), L485MB(X70), L555MB(X80)

PP PE 2PE 3PE API pipe according to standards API 5CT, API 5L, API 5LD, could be used in transfering oil, gas, water in oil field and mine

PE API pipe, with one layers of POLYETHYLENE (PE) to anti-corrosion,for fluid,oil and natural gas industry

2PE API pipe, with two layers of POLYETHYLENE (2PE) to anti-corrosion,for fluid,oil and natural gas industry

3PE API pipe, with three layers of POLYETHYLENE (3PE) to anti-corrosion,for fluid,oil and natural gas industry

PP API pipe, with three layers of POLYPROPYLENE (3PE) to anti-corrosion,for fluid,oil and natural gas industry

COATING STANDARD: DIN30670

SIZE: OUTSIDE DIAMETER FROM 159mm to 1600 mm.

PP,PE,2PE,3PE steel pipe cab be widely used in gas oil cgemical mine power thermodynamics and water industries for transportation meanwhile can be used for bridge pipeline,outside surface coated with PP or PE and inside surface coulded be coated with epoxy resin powder can decrease transportation resistance.

CERTIFICATE: ISO9001, UL, FM, CE, API

N.B	Epoxy powder coating	Adhesive(um)		Min wall thickness of anticorrosive coating (mm)
(mm)	(mm)	two layer	three layer	usual grade	strengthen grade
≤100	≥80			1.8	2.5
250		200-400	170-250	2.0	2.7
250				2.2	2.9
500				2.5	3.2
DN≥800				3.0	3.7
