Mine Industrial Convenient Vibrating Feeder With High Efficiency

Mine Industrial Convenient Vibrating Feeder with High Efficiency

Brief introduction

The Vibration Feeder (Vibratory feeder) is used to transfer the large size materials and granular materials from hopper to receiving device uniformly, periodically and continuously in the production flow and to feed materials into the crusher continuously and uniformly also to screen the materials in the sandstone production line. The vibrating feeder is widely used to match the crushing and sieving equipments in many industries including metallurgy, coal mine, mineral dressing, building material, chemical, grinding, etc.

Characteristics

Vibration Feeder is with simple structure, uniform feeding, continuous performance, and adjustable exciting force ; it subjects to change and control the flow, easy to operate; eccentric block as the excitation source, has the advantages of low noise, low power consumption, energy saving, no rushing material phenomena; the use of a closed fuselage to prevent dust pollution, which is good for stable vibration , reliable and long life; it also can adjust the vibrating forceat any time and control traffic, convenient adjustment and stability; vibration motor as vibration source, low noise, consumption power, the adjustment performance, non-red material phenomena. Reliable operation, adjustment, easy installation, light weight, small size, long performance life,easy maintenance are the most important features for our customers.

Working principle

GZD Series Vibration Feeder consists of a trough body, actuator, and spring bearings, gears and other components. The vibration source of the material tank is exciter. The parts of the exciter are two eccentric axis (active and passive) and the gear. The motor drives the axis through the belt, and then the gears of axis and the passive axis are engaged, and the passive axis running, Active and passive axis rolling in completely different directions at the same time, and the tank vibrating with the continuous flow of materials to achieve the purpose of conveying materials.

Technical parameter

Notice: This specification is just reference, any changes are subject to the product.

Notes during using:

1.Please read operation manual carefully before use.the machine may only be operated by fully authorized,trained personnel.

2.Make sure that the machine starts without any load. The machine can only be started after.All people are away from it.and wear safty hemlet and pay attention to flying stones,please atand outside the safe distance.

3.when machine runing All adjustment,clearance or check-up is strictly prohibited keep away from any running part. Overlaaded operation is strictly prohibited.

4.Lubriate and maintain the machine timelyBefore halt for check,feeder should be first stopped feeding and make sure the stones are all out of the machine silo.
