Help CenterHydraulic Cone Breaker With CE Approved
Related Products
Specifications
Hydraulic Cone Breaker1.stable structure
2.high efficiency
3.easy asjustment
4.perfect lubrication system.
Hydraulic Cone Breaker with CE Approved
Describtion of Cone Crusher
Hydraulic Cone Breaker is suitable for crushing various kinds of ores and rocks with medium or above medium hardness,and cone crusher is of stable structure, high efficiency, easy adjustment, and use economically, etc. The spring safety system of crusher acts as an overloading protection system that allows metals to pass through the crushing chamber and not damage the cone crusher.The safety system uses dry oil and water as two kinds of sealed formation to make plaster powder and engine oil separated to make sure reliable performance. The type of crushing chamber depends upon the usage of the crushed ores. The standard type(PYB) is applied to medium crushing, the medium type is applied to medium or fine crushing and the short head type is applied to fine crushing.
Hydraulic Cone Breaker with CE Approved
Working principle of cone crusher
The working parts are two cutter haeds, also called cones; one is fixed cone ( also called outer cone), the other one is movable cone ( also called inner cone), please refer to the picture. The outer cone is fixed, which is one part of frame; the movable cone is pluged freely in the eccentric bush, so the central axis between the fixed cone and the movable cone intersects and forms into a bevel. When rotating, the movable cone rotates along the inner suface of the fixed cone. The place that the movable cone pressed against the fixed cone becomes the crushing cavity, where the materials is pressed, impacted and bent by the movable cone. The place that the movable moves away from the fixed cone becomes the discharging open, where the crushed materials is discharged out under the role of gravity, and the materials are sent from the feed open.
Hydraulic Cone Breaker with CE Approved
Technical Data of Cone Crusher:
Model |
Diameter breaking cone (mm) |
Feed size (mm) |
range of discharge opening (mm) |
Max.feed size (mm) |
Capacity (t/h) |
speed of eccentric shaft (r/min) |
power (kw) |
Weight (T) |
Dimension(L*W*H) mm |
PYB600 |
600 |
75 |
12-25 |
65 |
40 |
356 |
30 |
5 |
2234*1370*1475 |
PYD600 |
600 |
40 |
2-13 |
35 |
12-23 |
356 |
30 |
5.5 |
2234*1370*1475 |
PYB900 |
900 |
135 |
15-50 |
115 |
50-90 |
333 |
55 |
11.2 |
2692*1640*2350 |
PYZ900 |
900 |
70 |
5-20 |
60 |
20-65 |
333 |
55 |
11.2 |
2692*1640*2350 |
PYD900 |
900 |
50 |
3-13 |
50 |
15-50 |
333 |
55 |
11.3 |
2692*1640*2350 |
PYB1200 |
1200 |
170 |
20-50 |
145 |
110-168 |
300 |
110 |
24.7 |
2790*1878*2844 |
Note: This specification is just for reference, any change is subject to the Hydraulic Cone Breaker products.
