Specifications
Gold Ore Crusher Machine1.large capacity,
2.high efficiency
3.long life,
4.energy-saving.
Jaw Crusher is widely used in mining, smelting, building materials, roads, railways, water conservancy and chemical industry and many other departments, non-breaking strength of more than 320 different kinds of materials MPa.
2) characteristics of Gold Ore Crusher Machine:
1. Deep broken cavity, no dead zone, increased capacity and output of the feed;
2. Large crushing ratio, uniform particle size products;
3. Pad-style nesting population adjustment devices, and ease of adjustment range, and increase the flexibility of the equipment;
4. Safe and reliable lubrication system, convenient replacement parts, small maintenance workload; 5. Structure is simple, reliable; low operating costs.
6. Energy-saving equipment: stand-alone energy-saving 15% ~ 30%; energy saving of the system is more than doubled;
7. The discharging size of jaw crusher can be adjusted to meet the requirements of different users;
8. Low noise and less dust.
3) Working Principle of IGold Ore Crusher Machine:
The motor drives the belt wheel, and makes movable jaw up and down by eccentric shaft. When the movable jaw down, the angle between the fixed jaw and movable jaw gets smaller, and the materials can be crushed to reach the crushing target. when the movable jaw rises, the angle between the fixed jaw and movable jaw becomes larger. The movable jaw plate leaves the fixed jaw plate under the function of drawbar. And spring, and then the crushed materials are discharged from the lower outlet of the crushing cavity.
4) Specifications of Gold Ore Crusher Machine:
Model |
Max. Feeding Size (mm) |
Discharge Size (mm) |
Capacity (t/h) |
Motor Power (kW) |
Overall Dimensions (mm) |
Weight (t) |
PE150×250 |
125 |
10-40 |
1-3 |
5.5 |
896×745×935 |
0.8 |
PE250×400 |
200 |
20-60 |
5-20 |
15 |
1150×1275×1240 |
2.8 |
PE400×600 |
350 |
40-100 |
15-60 |
30 |
1700×1732×1653 |
6.5 |
PE500×750 |
425 |
50-100 |
50-100 |
55 |
2035×1921×2000 |
10.3 |
PE600×900 |
480 |
65-160 |
60-130 |
75 |
2290×2206×2370 |
16.5 |
PE750×1060 |
630 |
80-140 |
80-180 |
110 |
2620×2302×3110 |
29 |
PE900×1200 |
750 |
95-165 |
140-260 |
110 |
3789×2826×3025 |
54.5 |
PE1000×1200 |
850 |
195-265 |
315-550 |
110 |
3335×3182×3025 |
57 |
PE1200×1500 |
1020 |
150-300 |
400-800 |
160-220 |
4200×3750×3820 |
100.9 |
PEX250×750 |
210 |
25-60 |
10-40 |
22 |
1667×1545×1020 |
5 |
PEX250×1000 |
210 |
25-60 |
15-50 |
30 |
1550×1964×1380 |
6.5 |
PEX250×1200 |
210 |
25-60 |
20-60 |
37 |
1560×2104×1415 |
7.7 |
Any change of technical data shall not be advised additionally!
