Hot sales mobile sand washing plant with high capacity for sale
Overview of sand washing plant
The XSD series Sand Washing Machines is a kind of water washing style washing and selecting equipment matched with the sand making machine and can clean the dust and stone powder which mixes with the final sand, so sand washing machine can improve the quality of the sand. The novel seal structure and reliable transmission, ensures the cleaning effect of dehydration. Sand washing equipment is an efficient equipment coordinate with sand making machine.
Working principle of sand washing plant
When the sand washing machine is running, the motor drives the impeller slowly turning through the belt, reducer, after the gear reduce the speed, sand and gravel are washed into the tank to the trough and driven by the the impeller, with tumbling and grinding each other to remove sand and gravel covered the surface of the impurities, while damages to the water vapor coated layer of sand to facilitate dehydration; at the same time, adding water to form a strong water flow, timely brings small proportion of impurities and foreign matter away and discharged from washing exports of the overflow tank, then finish the cleaning action. The cleaned sand and gravel are brought away from the blade, and finally poured into the out trough by the rotation of the impeller, and then finished the cleaning process.
Specification of sand washing plant
Model |
XSD2610 |
XSD2816 |
XSD3016 |
|
Impeller size (mm) |
2600×1000 |
2800×1600 |
3000×1600 |
|
Impeller rolling speed (r/min) |
1.178 |
1.177 |
1.179 |
Capacity(t/h) |
20-50 |
30-60 |
50-120 |
Max.feed size(mm) |
≤10 |
≤10 |
≤10 |
Motor Power (Kw) |
5.5 |
7.5-11 |
11-15 |
Reducer model |
ZQ50-50-I-Z |
ZQ65-50-I-Z |
ZQ65-50-I-Z |
|
Overall dimension (mm)
|
3255×1982×2690 |
3540×3000×2880 |
3845×3000×3080 |
Pictures of sand washing plant
Our working project
Our engineer and technical engineer
Services
Pre-sale:
(1) According to customer's special requirements, design and manufacture of products.
(2) The company free of charge to the user on-site engineering and technical personnel planning site for the user to design the best processes and programs.
After-sale:
(1) Free to assign a dedicated service personnel, arrived at the scene and guide customers installation.
(2) Complete sets of equipment installed.
Why Choose Us?
1. The machine in Kexing is actually good quality with preferential price.
* Good quality certificated with CE and ISO9001 quality management system;
* Careful producing process and standard technical in our factory.
* High output and large efficiency for the processing of produce.
2. The professional and customer-oriented services.
* We are manufacturer and our factory is located in Zhengzhou and have several working places in many countries.
* Our professional can help you address import issues, commodity visiting, certifcates and many details for the goods.
Contact information
Welcome to visit our products,if you have interest in it,please contact us through above ways!
