Product Description
Motorized Electric Lab Jack, Travel 5 mm
Specification
Model Number | 04DS5 |
Travel | 5mm |
Dimension | 50mmx64mm |
Driver | Ball Screw |
Guide | Sliding Guide |
Stepper Motor(1.8°) | SST42D2121 |
Material | Aluminum |
Surface Treatment | Black-Anodized |
Loading | 10kg |
Weight | 1.5kg |
Min Adjustment | 5μm(non-MS drive) 0.25μm(20-MS drive) |
Max Speed | 5mm/sec |
Repeatability | 7μm |
Backlash | 3μm |
Feature
*Regular stages set with stepper motors and RS232 interfaces, can connect with motion controller conveniently.
*High accuracy cross-roller guide for high performance and smooth moving
*Mounting holes both on the top and bottom of table for combine with other stages easily
*The stages can be redesigned.
Product drawings
