Motorized linear stage
Mini Motorized Linear Moving Stages
Model Number |
02DP15 |
02DP30 |
02DP50 |
Travel Range |
15mm |
30mm |
50mm |
Bearing |
Lead Screw (0.5mm of leading) |
Lead Screw (1mm of leading) |
|
Travel guide |
Crossed Roller Bearing |
||
Motor |
1.8°2-phase STP-42D3016 stepper motor (servo motor optional) |
||
Material- Finish |
Aluminum Alloy Black- Anodized |
||
Max Loading |
15kg horizontal/ 3kg vertical |
15kg horizontal/ 3kg vertical |
20kg horizontal/ 3kg vertical |
Weight |
1.3kg |
1.6kg |
1.8kg |
Resolution |
2.5um/ Pulse, non-ms driver 0.125um/ Pulse, 20 non-ms driver |
5um/ Pulse, non-ms driver 0.25um/ Pulse, 20 non-ms driver |
|
Max Speed |
5mm/ sec |
10mm/ sec |
|
Repeatability |
3um |
5um |
|
Absolute Accuracy |
8um |
||
Straightness |
8um |
||
Degree of Parallelization |
15um |
||
Pitching |
25’’ |
||
Yawing |
20’’ |
||
Backlash |
5um |
||
Optional Accessories |
Servo Motor, Motion Controller |
||
Features
*Regular type set with small 1.8°2-phase stepper motor
*Low-profile, high-accuracy for limited space use
*Crossed-roller bearing requires the precise movement
*Original position and limit switches are at both ends can supply the precision positioning and protection.
*Applies to use in single axis or assemble into multi-axis stages.
*RS232 interface for connecting motion controller easily
