Help CenterXDS510 DSP EMULATOR
Related Products
Specifications
XDS510 DSP EMULATOR1.Brand new & original
2.D/C:2012+PBF
3.warranty time 60 days
4. ex-stock source
ALTERA EPM7128STC100-15N
USB2.0 HIGH SPEED interface, plug and play, downward compatible with USB2.0 at full SPEED, as well as USB1.1 interface;
Standard 14 pin TI DSP simulator physical annotation JTAG interface definition, JTAG clock for the standard of 12 m.
Using 4 piece with 74 lv2g125 as interface chip buffer, the JTAG interface voltage range covers 1.2 V to 1.2 V, automatically ADAPTS to include leonardo Da Vinci, like all of the DSP chip JTAG OMAP part of voltage.
All external I/o use the ESD protection chip, prevent damage of body static electricity through JATG fragile TI DSP chips!
Support multiple DSP debug, can use Daisy chain mode to connect multiple DSP processors, and provide the technical support.
Using the comparator, op-amp circuit, such as the target board voltage real-time monitoring, to determine the board connection status.After completely overcome the target plate off electricity system crash;After power off cannot completely solve the target board to restart CCS.
Adopted the double color light, the red represents the target plate have no electricity or not connected target board.Green represents the target board has electricity.Red, green, said it was with DSP for data communication.Because CCS is an unusually large software system, the status on you determine the emulator state, thereby locking target hardware or software problem
USB to electricity, without external power supply, easy to carry and simulation transmission quickly, convenient for debugging
and production line to use.
Support software ]
Supporting css2. X, support CCS3. X, CCS4.1 development environment, (note: if you need to support CCS5. X software, can use the product under virtual machine, or contact customer service directly buy our "XDS510PLUS simulator").Support the C language and assembly language online real time debugging, support online debugging and FLASH programming, and the original product function exactly!
Shipping:
1. We can shipping all over the world by DHL , UPS , FedEx and EMS . The packaging is very safe and strong. If you have any special needs please nitfy me.
2. It will take around 3-5 days to reach your hands.
Product Type & Condition :
1. Because of the fluctuant sales situation. the stock parts are always changing and the stock list cannot be promptly updated . So,please consult the stock situation when you inquire.
Buyer Reading:
1. Please confirm receipt of products if the items you received , and if the goods was damaged please contact us immediately. send the photo to us that we can check and give you best solution .
2. We only guarantee Delivery in time but we couldn't control the express delivery time. Our related sales person will be responsible to send the AWB for the delivered goods in the next workday. you can check the AWB in the website which we send to you. For the AWB you also can call to the local branch of the express company in your company.
If you have any other questions please feel free to contact us in any time.
