Automatic Instant Rice Noodle Making Machine/Industrial
instant rice noodle plant/Rice Noodle Machine
The rice noodle making machine process is fully automatic from flour mixing,flour feeding,
first extruding,second extruding, noodles forming, cutting,aging, steaming,drying, cooling to packaging. Each process is strictly controlled to guarantee the noodles quality.
Products show: instant noodles of various flours
Automatic instant rice noodle making machine/
instant rice noodle plant/Industrial Rice Noodle Machine
Main device: industrial rice noodle making plant/Rice Noodle Extruder Machine/Rice Noodle Plant
1, flour mixer
2, ripening feeder
3, lifting conveyor
4, flour rationing feeder
5,rice noodle making machine/rice noodle machine/Rice noodle extruder machine
6, rice noodle rationing cutting machine
7, noodles combining conveyor
8, noodles adjusting machine
9, noodles distributing machine
10, rice noodle aging machine
11, rice noodle steaming machine
12, rice noodle drying machine
13, rice noodle cooling machine
14, connection conveyor
15, inspection conveyor
16, production conveyor
Spec.:instant rice noodle making machine/
Industrial rice noodle plant/Rice noodle making machine
Model |
SNTNRS8 |
Daily output |
80000pcs/24hrs (70g/pc) |
Hourly output |
3333pcs/hr |
Dimension |
57m*3.2m*3.6m |
Compressed air |
0.6 m3/min |
Steam |
500kg/h |
Water consumption |
3 tons for flour mixing |
Power |
108kw |
Operators |
7 persons |
Main feature: Rice Instant Noodle Making Machine/
Rice Noodle Plant /Rice noodle machine
|
1 Automatic production process The whole production line is highly controlled automatically from flour mixing to the final products, less manual operation. The operators only need to observe, monitor and adjust the equipments. |
|
2 Continuous aging process The automatic aging tunnel is adopted multi-level cycling design, go-and -back movement to shorten the machine length. To promote the aging effect and shorten the aging time, heat and humidity kept in side. |
|
3 Excellent drying effect To meet the drying curve demands and reach the excellent drying effect, we adopt the up-and- down multi-level design and divide the space of the dryer. Humidity and temperature is strictly controlled in each section. |
|
4 Precise weight control The weight of each piece noodle cake is stable, precisely controlled by the central system composed of frequency. |
|
5 Use kinds of flours as raw material wet milling rice flour, dry milling rice flour, starch flours etc. |
|
6 Multi- purpose machine Process different kinds of flours, products as instant rice noodle, starch vermicelli, wheat flour non-fried noodle, corn flour noodle, buckwheat noodles, oats noodle, barely noodle etc. |
Models: Instant rice noodle making machine/rice noodle making plant /Industrial Rice Noodle Machine
Model |
Daily output (70g/pc) |
Dimension (LxWxH)m |
Compressed air (m3/min) |
Steam Kg/h |
Power Kw |
Operators |
NRS4 |
40,000pcs |
55x2.8x3.6 |
0.6 |
330 |
86 |
7 |
NRS 8 |
80,000pcs |
57x3.2x3.6 |
0.6 |
500 |
108 |
7 |
NRS16 |
160,000pcs |
80x4.5x3.6 |
0.9 |
820 |
195 |
10 |
NRS24 |
240,000pcs |
80x6.5x3.6 |
1.2 |
1050 |
285 |
15 |
NRS36 |
360,000pcs |
110x6.5x3.6 |
1.5 |
1400 |
450 |
15 |
Technique support & good after sale service
Service System
1,supply solutions for the buyers’ special demands |
2,design plant layout and help complete the installation |
3,provide technical support both at setup and maintain |
4, train the operators |
Welcome to Saint Ngong Tat Machinery
Saint Ngong Tat Machinery Company (Tianjin) Limited (SNT for short) is the sole-venture
enterprise of Wang Wai Tat Machinery Company (Hong Kong) which specializes in the extruding
technology noodles making machine. SNT Machinery was established in Tianjin 1992. We have
developed several series of noodle machines, such as non-fried instant noodle, instant rice
noodle, rice vermicelli, stick rice vermicelli, starch vermicelli and vermicelli production line etc.
