CM-4040 Hot Sale CNC Router 0404
Standard features:
- Whole machine is cast-iron
- The machine adopts gantry movement, it can process any kinds of materials freely.
- Three axes adopt Taiwan Hiwin high precision square guide rails; X ,Y, Z axis adopts Germany-made ball screw,with high precision and longevity.
- Well compatibility: CAD/CAM designing software e.g. Type 3/Artcam/Castmate/Wentai etc.
- Has the function of re-carving after break point and power failure.
- Has the function of forecasting process time.
- Adopting advanced DSP Control system
- Adopting water cooling system, it can provide good cooling effect when carving flinty materials.
Applicable Industries:
Wood processing: processing of various furniture such as door, window, cabinet, craft wood door, screen and so on.
Advertisement: engraving and cutting various labels and number plate.
Art craft: engraving characters of any languages and graphics on gifts and souvenirs.
Applicable Materials:
Wood, aluminum board, plastic, density board, MDF board, wave board, PVC, acrylic,crystal, light marble and other nonmetal materials and light metal materials.
Description |
Parameter |
X,Y Working Area |
400*400mm |
Z Working Area |
70mm |
Resolution |
0.01mm |
Lathe Structure |
Cast-iron |
X,Y Structure |
Ballscrew transmission |
Z Structure |
Germanyrolling ball screw, Hiwin square guide rail |
Max. Idling Speed |
8m/min |
Spindle |
1.5KW |
Spindle Rotate Speed |
0-24000r/min, variable speed |
Inverter |
Fuling |
Working Voltage |
AC220V/50Hz |
Working Mode |
Stepper |
Driver |
Leedshine 542 |
Command |
G code,HPGL,U00,mmg,plt |
Operating System |
DSP with USB interface/Weihong |
Diameter of cutter |
φ3.175-φ12.7mm |
Cooling Mode |
Water-cooling |
Work-holding |
By suction or Clamp |
Net Weight |
100KG |
Gross Weight |
150KG |
