Top 10T Bitumen Emulsion plant,Asphalt Emulsion Plant
Application
GYRY10B asphalt emulsion plant is the 8th generation of asphalt emulsion equipment developed by our company. Emulsified asphalt of wide range of asphalt content and stable property produced by this equipment can meet various requirements of different construction technologies, which is applied into the express highway constructions and road maintenance projects.
Main Technical Parameters
Model: |
GYRY10B |
Max Capacitance: |
60kWh |
Power of Mill: |
30kW/22kW |
Rotation Speed of Mill: |
2930rpm |
Thermal oil Electrical Heating Power: |
9kWh |
Power of Burner: |
2.0×105kcal/h |
Heat Transfer Area: |
27m2 |
Fineness of Emulsified Asphalt: |
<5μm |
Productivity: |
10-12t/h |
Weight: |
6t |
Dimension: |
6500×2300×2700mm (L×W×H) |
Advantages
- This equipment applies automatic control system to monitor and regulate asphalt content in emulsified asphalt automatically. Two soap tanks are equipped to mix the materials and drain water in turn for continuous production. Flow rate is governed by electrical regulating valve, which saves human labor and reduces labor intensity.
- The key part of this plant - colloid mill is independently developed by our company. Its special structure of pilot rotors clearance is likely to keep tiny fixed clearance. It is made of special stainless steel with properties of wear resistance and corrosion resistance. Its emulsion fineness is less than 5μm.
- High efficiency plate heat exchanger is firstly equipped to cool the finished emulsified asphalt to improve the stability of emulsified asphalt storage; then to heat the cooling water for producing emulsified asphalt, which saves clear water heating expense to reduce production cost and makes the process environment friendly and energy saving, also makes successive micro-surfacing construction with emulsified asphalt possible (only emulsified asphalt of temperature lower than 40oC is acceptable in micro-surfacing construction.)
- PLC system controls production; electromagnetic flow meter collects signals; frequency governing motor controls the rotation speed of asphalt pump; electrical regulating valve or gate valve governs the emulsion flow rate (displayed by both electromagnetic flow meter and scale flow meter). By the above means, asphalt content in emulsified asphalt (ratio of asphalt to water) can be accurately and stably controlled.
- Independent and automatic thermal oil heating system is equipped to warm all the pumps before production, which is easy and convenient to replace baking with blowtorch.
- This plant is equipped with water boiler, no need of external thermal oil heating source. Efficient and pressure constant boiler can monitor and control the temperature instantly, quickly provide hot water for production.
- All the parts contacting the emulsion are made of qualified stainless steel with good anti-corrosion property to suit for production process of various kinds of emulsified asphalt.
As an experienced road maintenance machine manufacturer in China, we supply automatic
asphalt distributor, synchronous chip sealer, fiber chip sealer, asphalt emulsion plant,
intelligent asphalt rubber plant, intelligent micro surfacing paver (slurry paver), snow removal machines,
municipal road management equipment and more to customers all over the world.
With the efforts of our excellent and unceasing technical R&D team, we obtain 108 national
patents and 12 TOP products of China, 3 TOP products of the world. Our machine also support
the outstanding projects like the most famous street of China Chang An Avenue major repair
forthe 60th anniversary of the founding of PRC, 2010 Shanghai World Expo Park, Motorway of Shanghai Pudong International Airport, airstrip of Shanghai Hongqiao International Airport,
Motorway of Guangzhou Baiyun International Airport for 2010 Asian Games, etc.
Workshop
Certifications
We obsess professional and experienced technical service personnel,provide the users with low-cost and high-quality products and rapid-response services after sales.
